Fliptronic II Board
A-15472-1
J902
113
1000000000*0001
J905
r-~
a
a
r -,
*
0
a
O'l
a
~
a
a
a
a
'"
~
°
rna ~
CJ)
a
~ *
a
L{)
J904
2,1
1
34
~
L-
33
5
,
J903
J901-1 White-Blue, SOVAC from J104-1
J901-2 White-Blue, loop from J901-1
J901-3 White-Blue, SOVAC from J104-2
J901-4 Key
J901-S White-Blue, loop from J901-3
J902-1 Orange-Gray,
Sol
36
to playfield coil
J902-2 Not Used
J902-3 Yellow-Gray,
Sol
35
to playfield magnet
J902-4 Orange-Violet, holding upper right flipper
J902-S Not Used
J902-6 Yellow-Violet, power upper right flipper
J902-7 Orange-Blue, holding lower left flipper
J902-8 Not Used
J902-9 Yellow-Blue, power lower left flipper
J902-10 Key
J902-11 Orange-Green, holding lower right flipper
J902-12 Not Used
J902-13 Yellow-Green, power lower right flipper
J903 Ribbon Cable, data to/from J202; JS06; J601
J904-1 Gray, +SV to/from J114-4; J210-4
J904-2 Gray-Green, +12V to/from J114-2; J210-6
J904-3 Key
J904-4 Black, Ground to/from J114-7; J210-1
J906
/00*0001 100 00*01
6
,
6"
,
J904-S Black, Ground to/from J114-S; J210-3
,
J90S-1 Black-Violet, to right flipper opto
J90S-2 Blue-Gray, to left flipper opto
J90S-3 Black-Yellow, to right flipper opto
J90S-4 Key
J90S-S Black-Blue, to left flipper opto
J90S-6 Orange, Switch Ground
J906-1 Black-Green, to lower right EO.S. switch
J906-2 Key
J906-3 Black-Blue, to lower left E.O.S. switch
J906-4 Black-Violet, to upper right E.O.S. switch
J906-S Not Used
J906-6 Orange, Switch Ground
J907-1 Red-Green, +SOV to lower right flipper
J907-2 Red-Green, loop from J907-1
J907-3 Key
J907 -4 Red-Blue, +SOV to lower left flipper
J907-S Red-Blue, loop from J907-4
J907-6 Red-Violet, +SOV to upper right flipper
J907-7 Red-Violet, loop from J907-6
J907-8 Red-Gray, +SOV to upper left flipper
J907-9 Red-Gray, loop from J907-8
3-26
