UPPER PLAYFIELD PARTS
[~
~.~
;<1
:",l
~
Item Part Number
Description
..
~
No.
1 01-9211
Playfield Hanger Bracket (2)
37 A-19076
3 Switch Bracket Assembly
2 01-13593
Bottom Arch Ball Guide
38 02-5002
Large Ramp Post
3 A-15849-L -2
Flipper Assembly Complete
39 A-18955
Right Diverter Mech. Assy.
20-9250-5
Flipper
&
Shaft, White
A-19638-2
Knife
&
Diverter Assy., Right
4 01-12915
Left Drain Ball Guide
20-8712-25
E-ring 1/4"
5 A-19676-2
Left Flipper Ball Guide
4700-00027-00 Flat Washer .1/4 x 1/2 21 G
6 12-6466-10
Ball Guide Wire 2 1/2" (2)
40 A-19061
Ball Guide
7 A-17811
Sling Shot Kicker Assembly
41 A-19679
Ball Stop Assembly
B-9362-R-3
Coil
&
Bracket Assembly
42 A-15368
Eject Assembly
10-128
Spring
A-17985-R
Eject Switch Assembly
8 A-17813
Rollover Switch Assembly (6)
43 A-19060
Ball Guide
9 A-H801
Kicker Count Switch Assy.
44 A-18515
Inner Sanctum Ball Guide RI.
10 02-5107
Adjusting Post (2)
45 A-17855
Large Ramp Assembly
11 A-18019-6
Skirted Target, Yellow (4)
46 A-19700
Right Drain Wire Ramp Assy.
12 A-18530-6
Oblong Target, Yellow (3)
47 A-15849-R-4
Flipper Assembly Complete
13 A-17854
Small Ramp Assembly
20-9250-5
Flipper
&
Shaft, White
14 A-19702
Left Drain Wire Ramp Assy.
48 01-19218
Upper Flipper Ball Guide
15 A-17794
Kicker Switch Assembly
49 A-19603-3
Right Mongol Plastic Assy.
16 A-19603-4
Left Mongol Plastic Assembly
50 A-19701
Wire Ramp Assembly
17 01-12921
Left Eject Ball Guide
51 A-19730
Shooter Ramp Assembly
18 02-5001
Small Ramp Post
52 A-17811
Sling Shot Kicker Assembly
19 A-H838
#8 Stud Plate
B-9362-L-2
Coil
&
Bracket Assembly
20 A-18954
Left Diverter Mech. Assembly
10-128
Spring
A-19638-1
Knife
&
Diverter Assy., Left
53 A-19676-1
Right Flipper Ball Guide
20-8712-25
E-ring 1/4"
54 A-18513
Right Drain Ball Guide
4700-00027-00 Flat Washer .1/4 x 1/2 21G
55 A-15849-R-2
Flipper Assembly Complete
21 A-18768
Eject Assembly
20-9250-5
Flipper
&
Shaft, White
A-19693
Micro Switch
&
Bracket Assy.
56 A-18753
Ball Trough Assembly Compo
22 A-19066
Left Popper Ball Guide Assy.
57 A-18973
Shooter Lane Switch Assy.
23 A-18537
Bracket Assembly
58 A-14525
Kicker Bracket Assembly
02-5061
Post 6-32 x 3/8"
59 A-15802-P
Level & Holder Assembly
24 A-18512
Upper Loop Ball Guide Assy.
60 01-10621
Strike Plate
25 A-18518
Opto Bracket Assembly
61 A-18382
Mini-playfield Assy. Compo
26 A-19642
1-Bank Drop Target Assembly
a) A-17789
Coil Slide Motor Assembly
27 A-18388
Magnet Opto & Nut Assembly
b) 03-9229
Plastic Guard
28 A-18950
Ball Popper Assembly
c) A-19603-1
"Front Plastic Guard
29 12-7241
Mini-Playfield Wire Ramp
d) 02-5142
Thumb Screw
30 A-18622
Extended Target Assembly
e) A-18379-6
Recl. Target Assy. Yellow (7)
31 A-18514
Main Loop Short Ball Guide
f) A-19603-2
tLow Plastic Guard
32 01-12916
Main Loop Long Ball Guide
g) A-19113-2
Left Mounting Bracket
33 A-18529
Back Panel Assembly
h) A-18783
4-Bank Drop Target Assembly
33a 03-9215-2
Bottom Half Tube
i) A-19113-1
Right Mounting Bracket
34 A-13505-1
Ball Gate Assembly
62 A-19786
Mini-playfield Back Board Assy.
35 A-19052
Inner Sanotum Ball Guide Left
A-19522
"Detlector Assembly
36 A-18952
Ball Kicker Assembly
03-9214
*Mini-playfield Rear Ramp
01-13111
Cam
63 A-19794
Switch Gate Assembly
03-9252
Spacer
4700-00008-00 Flat Washer 5/32 x 5/8 x 21G
2-44
