PARTY ZONE
A-14909 Back Panel Assembly
Item Part Number
Description
1.
A-13100-1
Ball Gate Assembly
2.
A-14859
Light Assembly
a)
C-13337
PCB
&
Light Assembly
* 3.
A-14863
Ball Popper Assembly (See p. 2.28)
4.
A-14910
Back Panel Sub-Assembly
5.
12-6984
Wire Ramp
6.
4106-01033-08
Sh. Metal Screw, #6 x
1/2"
7.
4006-01003-12
Mach. Screw, #6-32 x
3/4"
8.
4008-01016-10
Mach. Screw, #8-32 x
5/8"
9.
4008-01005-06
Mach. Screw, #8-32 x 3/8"
10.
4700-00016-00
Flatwasher,
3/16
x 7/16 x 17ga.
11.
4701-00003-00
Lockwasher #8 Split
12.
01-9170
Gusset Bracket
13.
4008-01015-12B Mach. Screw, #8-32 x 3/4
*14.
A-14983
Mandible Mech. Assembly (See p. 2.29)
15.
4106-01114-08
TCS #6 x 1/2
16.
A-14761
Bracket
&
Lamp PC Board
a) A-14767
3-Lamp Board
b) A-14802
Head Bracket Assy.
c) 07 -6688-17N
Rivet,
5/32
x
1/8"
17.
03-8597
Robotic Comic Head Assembly
18.
4006-01003-06
Mach. Screw, #6-32 x
3/8"
19.
24-8768
Bulb #555 (6.3v, .25A)
20.
03-8063-6
Sleeve, Yellow
21.
03-8063-4
Sleeve, Red
22.
H-14953
Solenoid Cable
23.
H-14956
Switch Cable
* Refer to unit's individual
parts listing.
2.26
