B-9361-R-1
Ball Eject Assembly
w/Coil & Bracket Assembly:
8-9362-L-2
Item Part Number
Description
1.
A-6949-R
Spring Plate
2.
A-7471-R
Eject Cam Assembly
3.
A-8050-1
Plunger Assy., 2-1/8"
a)
02-3407-2
Plunger Coil
b)
03-8085
Armature Link
c)
20-8716-5
Roll Pin, 1/8 x 7/16"
4.
A-8268
Mounting Bracket Assy.
5.
10-362
Eject Spring
6.
12-6227
Hairpin Clip
7.
4700-00030-00
FW, 17/64 x 1/2 x 15ga.
8.
4700-00103-00
FW, 17/64 x 1/2 x 28ga.
Associated Parts:
9.
03-7351-1-9
Eject Shield
10.
B-9362-L-2
Coil & Bracket Assy.
a) AE-26-1200
Coil Assembly
b) B-7572-1
Bracket & Stop Assy.
c)
01-8-508-S
Coil Retainer Bracket
d)
03-7066
Coil Tubing
e)
4006-01017-06
Mach. Screw, 6-32 x 3/8
f)
4406-01119-00
Nut, 6-32 ESN
2.23
PARTY ZONE
