A-14039 Dot Matrix Controller Assembly
I
JtEtIl1
ParfNornber
Ckt ••[)jJslgnllt(jr
....Desci'lptl()tl
1
5010-08991-00
R1
Resistor, 4.7KQ, 1/4w, 5%
2
5010-09224-00
R10
Resistor, 270n, 1/4w, 5%
3
5010-09534-00
R7
Resistor, on
4
5010-12832-00
R3,R6,R12,R13
Resistor, 47KQ, 1/2w, 5%
5
5010-12841-00
R4,R5
Resistor, 1200, 1/2w, 5%
6
5012-12830-00
R9
Resistor, 1.8KQ, 5w, 5%
7
5012-12842-00
R11
Resistor, 1200, 5w, 5%
8
5012-12843-00
R8
Resistor, 4.7K, 5w, 5%
9
5040-08986-00
C3
Capacitor, 100llfd., 10v, (±20%)
10 5040-12324-00
C4, C7
Capacitor, 150llfd., 160v, (±50%)
11 5043-08980-00
BYPASS
Capacitor, .01Ilfd., SOv, (+80, -20%)
12 5043-09072-00
C6, C9, C10
Capacitor, .tutd., SOOv, (+80, -20%)
13 5043-09845-00
C1, C2, C11
Capacitor, 1KP, 50v, (±20%)
14 5070-09054-00
07
Diode, 1N4004, 1.0A.
15 5075-12824-00
06,08
Zener, 1N4742A, 12v
16 5075-12823-00
03 - 05
Zener, 1N4758A, 62v
17 5100-12833-00
BR1, BR2
Bridge, 401)v, 1A.
18 5160-10269-00
01
Transistor, 2N3904 NPN
19 5164-09056-00
02, 010
Transistor, MPS002, NPN
20 5164-12154-00
03,07
Transistor, MJE15030 NPN
21 5194-09055-00
04,05
Transistor, MPS052 PNP
22 5194-12155-00
06
Transistor, MJE15031 PNP
23 5281-09738-00
U16, U25 - U27
IC,74LS157
24 5281-1 0033-00
U3
IC,74LS30
25 5281-10043-00
U31 - U33, U35
IC,74LS175
26
5311-10946-00
U4, U5, U17, U18,
IC,74HC74
U20
27
5311-10947-00
U9
IC,74HC125
28
5311-10951-00
U10,U11
IC,74HC161
29 5311-10977-00
U6
IC,74HC04
30
5311-12817-00
U29
IC,74HC165
31
5311-12819-00
U21
IC,74HC688
32
5311-12820-00
U23
IC,74HC27
33
5311-12822-00
U13 - U15
IC,74HC193
34
5315-12009-00
U22
IC, 74HCT374
35
5315-12812-00
U1, U2, U30
IC,74HCT138
36
5281-09308-00
U28
IC, 74HCT245
37
5315-12815-00
U8,U34
IC,74HCT08
38
5315-12816-00
U19
IC,74HCT32
39
5315-12821-00
U7
IC, 74HCT240
40
5340-12278-00
U24
S/RAM 2064 150NS
41
5551-09822-00
L1
INO 4.7IlH, 3.0A.
42
5671-09019-00
010
Oisplay LEO Red
43
5705-09199-00
03, 06, 07
Heatsink 6030B
44
5731-12328-00
F601, F602
Fuse, 3/8A.,SB, 250v
45
5733-12060-00
Fuse Holder (F601, F602)
46
5760-12710-00
PC Board
47
5791-10850-00
J602
Connector, 26-pin STR Sq.
48
5791-10862-05
J605
Connector, 5-pin Header Sq.
49
5791-10862-07
J606
Connector, 7-pin Header Sq.
50
5791-10862-08
J604
Connector, 8-pin Header Sq.
51
5791-12516-00
J601
34 Hen 17x2 STR
52
5791-12827-00
J603
14 Hen 7x2 STR
53
5010-09036-00
R14-R23
Resistor, 100n, 1/4w, 5%
54
20-9229
03,06,
07
Thermal Compound
55 4006-01003-06
03,06,
07
Mach. Screw, 6-32 x 3/8
56
4406-01128-00
03,06,
07
Nut, 6-32 KEPS
57
5043-09492-00
C5, C8
Capacitor, ioos. 50v, (±10%)
58
5010-10171-00
R7
Resistor, 56n, 1/4w, 5%
PARTY ZONE
2.12
