locations Diagram -
Game Major Mechanisms
Underside of Playfield, Viewed in Raised Position
A-8039-3
Outhole Assy.
C-13174-R
Right Flipper Assy.
C-13174-L
Left Flipper Assy.
B-12665
Kicker Arm Assy.
B-11203-R-1
Coil & Bracket Assy.
A-14768
High Driver Assy.
A-14766
Motor Opto Board
A-14756
Captain B.Zarr
A-12842-4
Jumper Bumpers(3)
A-14808
Dancer Mech. Assy.
A-14860
Ramp Assembly
C-9638
~--l--
Ball Shooter Assy.
B-9362-L-2
Coil & Bracket Assy.
~ __ -+__
B-12665
Kicker Arm Assy.
B-11203-L-1
Coil
&
Bracket Assy.
®j----\r;;o\:------l--
B-9361-R-1
Ball Eject Assembly
B-9362-L-2
Coil
&
Bracket Assy.
1------+--
0-11335-2
Ball Popper Assy.
A-14909
Back Panel Assy.
• Lamp Boards
A-14863
Ball Popper Assy.
A-14983
Mandible Assy .
Item Part Number
Description
A A-14774
7-Lamp Assembly
B A-14775
5-Lamp Assembly
C A-14776
5-Lamp Assembly
D A-14778
4-Lamp Assembly
E A-14777
4-Lamp Assembly
Item Part Number
Description
F
A-14779
3-Lamp Assembly
G
A-14781
3-Lamp Assembly
H
A-14780
4-Lamp Assembly
J
C-13337
Single Lamp Assy.
PARTY ZONE
