T.8 Single Lamp Test ~
For all lamps, the number on the left indicates the column, the number on the right
indicates the row. Example- Lamp 23 means 2nd column, 3rd row.
Once the test name is shown under the Test Menu, press the Enter button. This test allows you
to test each lamp circuit individually. Press the Up or Down button to cycle through this test. For
each name and number that is shown in the displays the corresponding lamp should light. Any
other results indicates the system has detected a problem. Press the Start button to obtain wire
color, connector, and fuse information when the desired lamp is lit.
Press the Escape button to return to the Test Menu. Press the Up button to display the next test,
(or the Down button to return to a previous test). Press the Enter button to activate that test.
,.,
T.9 All Lamps Test
Once the test name is shown under the Test Menu, press the Enter button. This test causes all
the controlled lamps to flash at the same time. Every controlled lamp should flash. Any other
results indicates the system has detected a problem.
Press the Escape button to return to the Test Menu. Press the Up button to display the next test,
(or the Down button to return to a previous test). Press the Enter button to activate that test.
c,
,
T. 1
0 Lamp and Flasher Test
1
Once the test name is shown under the Test Menu, press the Enter button. This test causes all
the flash lamps and the controlled lamps to flash at the same time. The controlled lamps blink,
while the flash lamps cycle from highest to lowest. Any other results indicates the system has
_I
detected a problem.
.
t
Press the Escape button to return to the Test Menu. Press the Up button to display the next test,
(or the Down button to return to a previous test). Press the Enter button to activate that test.
PARTY ZONE 1-33
