T.4 Solenoid Test
Once the test name is shown under the Test Menu, press the Enter button. The Solenoid Test
has three modes, Repeat, Stop, and Running. Only one solenoid should turn On at a time. The
system has detected a problem if, more then one solenoid turns On, a solenoid comes On and
stays On, or no solenoid turns On during the Repeat or Running test modes. Press the Start
button to see the wire color, driver number, connector and, fuse information of any coil, when that
coil is displayed.
Repeat
Stop
This test allows you to stop and pulse a single coil or flashlamp. Once you have
entered the Solenoid Test, coil 1 shows in the displays and the corresponding
solenoid activates. Press the Up or Down button to cycle through the solenoids,
one at a time, manually. The same solenoid pulses until you press the Up or
Down button to move to the next one. Either press the Escape button to return
to the Test Menu, or press the Enter button to move to the next test mode.
- ,
This test allows you to stop the Solenoid Test at any point. Press Enter during the
Repeat test mode and the Solenoid Test stops. There should not be any
solenoids activated while the test is stopped. Either press the Escape button to
return to the Test Menu, or the Enter button to move to the next test mode.
This test allows you to cycle through the solenoids automatically. Press the Enter
button during the Stop test mode. The displays show you the name and number
of the solenoid currently being pulsed.
Either press the Enter button to return to the Repeat test mode, or press the Escape button to
return to the Test Menu. Once in the Test Menu press, the Up button to display the next test, (or
the Down button to return to a previous test). Press the Enter button to activate that test.
Running
T.5 Flasher Test
Once the test name is shown under the Test Menu, press the Enter button. This test allows you
to test the flashlamp part of the solenoid circuit exclusively. This test, like the Solenoid Test, has
three test modes Repeat, Stop, and Running. During this test, only one flashlamp circuit should
tum On at a time. If, more then one flashlamp circuit turns On, or stays On, or no flashlamp circuit
turns On at all during the Repeat or Running test modes the system has detected a problem.
Press the Start button to see the wire color, driver number, connector, and fuse information of any
flash lamp circuit when that circuit appears in the displays.
Repeat
Stop
Running
This test allows you to stop and pulse a single flashlamp. Once you have entered
the Flasher Test the name and number of the first flashlamp circuit shows in the
displays and the corresponding bulb(s) flashes. Press the Up or Down button to
cycle through all of the flash lamps circu~s one at a time, manually. The same
flash lamp circuit pulses until you press the Up or Down button to move to the
next one. Either, press the Escape button to return to the Test Menu, or press
the Enter button to advance to the next test mode.
This test allow you to stop the Flasher Test at any time. Press the Enter button
during the Repeat test mode. The Flasher Test stops. There should not be any
flashlamp circuit turned On during this test mode. Either press the Escape button
to return to the Test Menu, or press the Enter button to advance to the next test
mode.
This test allows you to cycle through the flash lamps automatically. Press the
Enter button during the Stop test mode. The displays show you the name and
number of the flashlamp currently being pulsed, and the corresponding bulb(s)
flashes.
PARTY ZONE 1-28
