Press the Enter button to activate the Test Menu, once the menu name is shown under the Main
Menu. Then, use the Up or Down button to cycle through the Test Menu selections. Press the
Enter button to activate the desired test when that test appears in the displays.
T .1
T.2
T.3
T.4
T.5
T.6
T.7
T.8
T.9
T.10
T
.11
T .12
T. TEST MENU
Switch Edges
Switch Levels
Single Switch
Solenoid Test
Flasher Test
General
Illumination
Sound
&
Music Test
Single Lamps
All Lamps
Lamp
&
Flasher Tests
Display Test
Motor Test
' )
T.1 Switch Edges
'
;......
••••••.•~,..,.~
For all switches, the number on the left indicates the column, the number on the right
indicates the row. Example- Switch 23 means 2nd column, 3rd row.
To test the Left and Right Flippers, press the Left or Right Flipper buttons during switch test. The
flipper name and switch number should show in the displays. Any other results indicate the
system has detected a problem with the flipper circuit.
To activate the Switch Edges Test, from the Test Menu, press the Enter button. The name and
number of each switch that is pressed is shown in the displays. If any other switch, or no switch at
all is indicated, the system has detected a problem with the switch circuit.
r>.
I
Press Escape to return to the Test Menu. Press the Up button to display the next test, (or the
Down button to return to a previous test). Press the Enter button to activate that test.
T.2 Switch Levels
Once the test name is shown under the Test Menu, press the Enter button. The name and
number of each switch that is activated is shown in the displays. This test automatically cycles
through all switches that are detected closed. Current switch is indicated by a filled square.
Press the Escape button to return to the Test Menu. Press the Up button to display the next test,
(or the Down button to return to a previous test). Press the Enter button to activate that test.
T.3 Single Switches
Once the test name is shown under the Test Menu, press the Enter button. The Single Switch
Test isolates a particular switch by blocking signals from all other switches. Use the Up or Down
buttons to select the switch to be tested. During the Single Switch Test, a flashing cross indicates
your location in the matrix, a square indicates a closed switch, and a dot indicates an open switch.
Press the Start button to obtain wire color, connector, and fuse information of any switch when
that switch is displayed.
Press the Escape button to retum to the Test Menu. Press the Up button to display the next test,
(or the Down button to return to a previous test). Press the Enter button to activate that test.
