Press the Up button to advance to the next desired Adjustment Group, (or press the Down button
to return to a previous Adjustment Group). Press the Enter button to activate that group. Press
the Up or Down button to cycle through the available adjustments in that group.
A.S Printer Adjustments
(optional board required)
A.S 01
A.S
02
A.S 03
A.S
04
A.S
05
A.S 06
Column Width
The operator chooses the column width to be printed. The range of this setting is
22 through 80.
Lines Per Page
The operator chooses the amount of lines per page. The range of this setting is
20 through 80.
Pause Every Page
The operator chooses whether the printer pauses at the end of a page. The
choices are:
YES
The printer does pause.
NO
The printer doesn't pause.
Printer Type
The operator selects which kind of printer to use. The choices are Parallel, Serial
or ADP.
Serial Baud Rate
The operator selects which baud rate to use for Serial or ADP communications (bit
rate). The choices are 300,600, 1200,2400,4800.
or 9600.
Serial D.T.R. (Data Terminal Ready)
When a Serial Printer is used, this line may be connected to a printer output line
signaling that the printer is busy.
Normal
=
Normal D.T.R. signal goes low to indicate the printer is not ready.
Inverted
=
Inverted D.T.R. (busy) signal goes high to indicate printer is not
ready.
Ignore
=
D.T.R. signal is ignored.
Press the Escape button to return to the Adjustments Menu. Then, either press the Up or Down
button to return to a previous Adjustment Menu Group, or press the Escape button again to
return to the Main Menu. Once in the Main Menu, either press the Up button to advance to the
next menu selection, the Bookkeeping Menu, or press the Down button to to return to a previous
Main Menu selection.
