Basic HTML Version
MAIN MENU
A.
Adjustments
B.
Bookkeeping
P .
Printouts (optional board required)
T.
Tests
U.
Utilities
The game Adjustments are the first category available from the Main Menu. Press the Enter
button to activate the Adjustments Menu. Press the Up or Down button to cycle through the
Adjustment Menu selections.
Press the Enter button to activate the desired Adjustment Group
when that group appears in the displays.
A. ADJUSTMENTS MENU
I
I
,
A.1 Standard Adjustments
A.2 Feature Adjustments
A.3 Pricing Adjustments
A.4 H.S.T.D Adjustments
A.5 Printer Adjustments (optional board required)
Once you have entered the adjustment group desired, press the Up or Down button to cycle
through the available adjustments in that group. When the desired adjustment appears press the
Enter button to activate that adjustment. When an adjustment is activated, the setting value
begins to flash. Use the Up or Down button to raise or lower the setting value. When the desired
value is displayed press Enter to lock in the value. IF you realize you have made an error, press
the Escape button while "Saving Adjustment Value" is displayed. The new value is ignored and
i
the original value is retained.
A.1 Standard Adjustments
A.1 01
Balls Per Game
The operator defines a "game" by specifying the number of balls to be played.
The range of this setting is 1 through 10.
A.1 02
Tilt Warnings
The operator specifies the number of total actuations of the plumb bob
mechanism that can occur before the game is "tilted". The range of this setting is
1
through
1O.
A.1 03
Maximum Bonus Balls
The operator chooses the number of Bonus Balls that a player may accumulate.
The range of this setting is 1 through 10, or "No Bonus Ball" (Bonus Ball
disabled).
A.1 04
Maximum Bonus Balls/Ball
in Play
The operator chooses the number of Bonus Balls to be awarded per ball in play.
The range of this setting is:
OFF
1-10
No maximum number of Bonus Ball per ball in play.
1 through 10 Bonus Balls per ball in play.
PARTY ZONE 1-8
