INTERBOARD WIRING
Solenoid Circuits
Connectors From Power Driver Board:
Wire Color Function
To Backbox To
Pla~field
Transistor
Violet/Brown Solenoid 1, High Power
J130-1
082
Violet/Red
Solenoid 2, High Power
J130-2
080
Violet/Orange Solenoid 3, High Power
J130-4
078
VioletIY ellow Solenoid 4, High Power
J130-S
076
Violet/Green Solenoid S, High Power
J130-6
064
Violet/Blue
Solenoid 6, High Power
J130-7
066
Violet/Black
Solenoid 7, High Power
J130-8
068
Brown/Black Solenoid 9, Low Power
J127-1
OS8
Brown/Red
Solenoid 10, Low Power
J127-3
OS6
Brown/Orange Solenoid 11, Low Power
J127-4
OS4
BrownNeliow Solenoid 12, Low Power
J127-S
OS2
Brown/Green Solenoid 13, Low Power
J127-6
OSO
Brown/Violet
Solenoid 1S, Low Power
J127-8
046
Brown/Gray
Solenoid 16, Low Power
J127-9
044
BlacklBrown Sol. 17, Flasher 1, No Diode
J126-1
J12S-1
042
Black/Red
Sol. 18, Flasher 2, No Diode
J126-2
J12S-2
040
Black/Orange Sol. 19, Flasher 3, No Diode
J126-3
038
BlacklYeliow Sol. 20, Flasher 4, No Diode
J126-4
J12S-S
036
Blue/Green
Sol. 21, Special 1 Drive
J126-S
J12S-6
028
Blue/Black
Sol. 22, Special 2 Drive
J126-6
J12S-7
030
BlueNiolet
Sol. 23, Special 3 Drive
J126-7
034
Blue/Gray
Sol. 24, Special 4 Drive
J126-8
032
Blue/Brown
Sol. 2S, Special S Drive
J122-1
026
Blue/Red
Sol. 26, Special 6 Drive
J123-3
J122-2
024
Blue/Orange Sol. 27, Special 7 Drive
J123-4
J122-3
022
BlueNeliow Sol. 28, Special 8 Drive
J123-S
J122-4
020
Flipper Circuits
Connectors From Power Driver Board:
Wire Color
GrayNellow
Function
Left Flipper Power
To Pla~field
J109-S
BlueNeliow Right Flipper Power
J109-7
Blue/Gray
Lower Left Flipper
J109-3
BlueNiolet
Lower Right Flipper
J109-4
Blue/Gray
Lower Left Flipper
J110-7
BlueNiolet
Lower Right Flipper
J110-6
Orange/Gray Left Flipper Ground
J110-2,1
OrangeNiolet
Right Flipper Ground
J110-4,3
PARTY ZONE 3-8
