PLAYFIELD PARTS
Item Part Number Description
51 12-6999
Ball Guide Wire
52 A-14929
Ball Gate Assy.
1 A-14859
Light Assy.
53 A-14856
Ball Guide Assy.
2 A-14860
Ramp Assy.
54a B-9362-L-2
Coil
&
Brkt Assy.
3 01-9170
Gusset Brkt.
b B-9361-R-1
Eject Assy.
4 A-8244-L
Ball Gate Assy.
c A-9381-R
Switch Assy.
5 12-6466-3A Wire Guide 7/8"
d 03-7351-1-9 Red Shield
6a A-14803
Dancing Dummy Assy.
55 01-6933
Ball Stop
b A-14808
Dancer Mech Assy.
56 A-14855
Ball Guide Assy.
7 03-8318-16
Yellow Light Hood
57 A-14857
Ball Guide Assy.
8 12-6997
Ball Guide Wire
58 A-14930
Ball Gate Assy.
9 A-14853
Ball Guide Assy.
59 A-14760
Cosmic Cottage Assy.
10 A-14984
Upper Left Ramp Assy.
60 B-12912-24 White Target Assy. (3)
11 A-14852
Ball Guide Assy.
61 12-6983
Wire Ramp
12 A-14883
Rocket Assy
62 A-14858
Ball Guide Assy.
13 A-12842-4
Jumper Bumper Assy.
63 A-14932
Ball Guide Assy.
14a 02-4436-18
Ramp Mtg. Post 1 11/16
64 A-14850
Ball Gate Assy.
b 02-4335-13
Ramp Mtg. Post 1 9/16
65a D-11335-4
Ball Popper Assy.
15 02-4335-9
Ramp Mtg. Post 1.94
b A-11657
Ball Popper Switch
16 A-14756
Capt. B. Zarre Assy.
66 A-14851
Ball Guide Assy.
A-15008
Head Mech. Assy.
67 A-14937
Ball Gate Assy.
A-14759
Brkt.
&
Motor Assy.
68 12-6996
Ball Guide Wire
12 .
_~~:1~604-20 Oran.ge T!;uget
Ass,¥- ...,,"
69 A-13100-1
Ball Gate Assy.
[L8 __ .A:I4 793-1~_ ~_yellO~IE!g~
\
70a A-14802
Head Brkt Assy.
19 A-14854
Ball Guide Assy.
b A-14983
Mandible Mech. Assy.
20 02-4567-1
Ramp Mtg. Post 2 5/16
c A-14761
Lamp Board
&
Brkt.
21 B-12912-21
Green Target Assy. (6)
71 A-14909
Back Panel Assy.
22 03-8584
Lower Left Ramp
72 A-14863
Ball Popper Assy.
23 01-9510
#8 Adj. Post Plate
73 12-6984
Wire Ramp
24 01-10375
Ball Deflector
74 02-4252-9
Ramp Mtg. Post 9/16
25a B-11203-R-1 Coil
&
Brkt. Assy.
75 A-14930
Ball Gate
&
Switch Assy.
b B-12665
Nylon Kicker Assy.
26 B-8284-1
Kicker Count Switch
27 B-12919
Flipper Ball Guide Assy.
Not Shown:
28 C-13174-L
Flipper Mech Assy.
A-13204-20004
Bottom Arch Assy.
29 20-9592-7
Flipper Bat Assy.
12-6842
Wire Fence
30 12-6871
Biff Bar
16-20004-1
Instruction Card
31 01-3569-1
Ball Return Runway
20-9041
Tinnerman
32 01-5575
Bottom Arch Mtg. Brkt.
20-9045
Instruction Card Cover
33 01-8419
Plyfld Hold Down Brkt.
23-6313-1
Grommet
34 12-6542
Wire Gate
31-1008-20004
35 A-8039-3
Ball Release Assy.
20004- Plastics
Playfield Plastics Set
36 A-8645
Wire Form
&
Brkt. Assy.
31-1002-20004
Screened Playfield
37 B-8623
Guide
&
Baffle Assy.
01-10413
Metal Ramp Cover
38 B-8925
Micro Switch Plate Assy.
03-7557
Slingshot Mylar
39 B-9362-L-2
Coil
&
Brkt. Assy.
·03-7960-20004-1
Full Playfield Mylar
40 C-8235
Ball Runway Assy.
03-7960-20004-2
Jet Area Mylar
41 C-9638
Multi-Ball Eject Assy.
03-7966
Ball Drop Mylar
42 C-13174-R Flipper Mech Assy.
20-6500
Steel Ball (3)
43 B-12918
Flipper Ball Guide Assy.
A-14632-2
Cable Clamp Brkt. Assy.
44a B-11203-L-1 Coil
&
Brkt. Assy.
A-14632-3
Cable Clamp Brkt. Assy.
b B-12665
Nylon Kicker Assy.
A-14632-4
Cable Clamp Brkt. Assy.
45 02-4568-1
Ramp Mtg. Post 1 9/16
46 A-14911
Right Ramp Assy.
• The Party Zone Diamond Plate
™
playfield
47 B-12912-20
Orange Target Assy.
does not require a full mylar. However, mylars
48 B-12912-19 Yellow Target Assy.
can be purchased thru your local Bally
49 B-12912-22
Blue Target Assy.
Distributor.
50 02-4567-3
Ramp Mtg. Post 2 5/8
PARTY ZONE
2.44
