A-14007 Chase Light Assembly
n
Cl 21 " 11 9'1 51 t1 ,
-s
s
us
10
I ,.,
J3
,
,
Item Part Number
Ckt Designator
DeSCription
1 5768-12705-00
PCB Chase LI~ht
2 5162-08976-00 Q1 -Q16
Tras. 2N6427 PN
3 5010-08997-00 R10 - R25
Resistor, 2.7Kn,
1/4w, 5%
4 5010-09034-00 R7- R9
Resistor, 10Kn,
1/4w, 5%
5 5010-09358-00 R3,R4
Resistor, 1Kn,
1/4w, 5%
6 5010-09162-00 R5
Resistor, 100Kn,
1/4w, 5%
7 5010-09113-00 R6
Resistor, 33Kn,
1/4w, 5%
8 5010-08930-00 R1,R2
Resistor, 470n,
1/4w, 5%
9 5040-09365-00 C2
Capacltor,11lfd,
63v
(+50, -10%)
10 5040-09421-00 C1
Capacitor, 100llfd,
25v
(+50, -10%)
11 5043-08980-00 BYC1-BYC4
Capacitor, .01~d, 50v, (+80, -20%)
12 5281-09867-00 U4,U5
IC, 74LS244, ct. Buff
13 5281-10447-00 U2,U3
IC,74LS164
14 5370-12272-00 U1
IC, LM339 Quad. Comp
15 5250-09157-00 U6
Reg 7805, 1.0A. 5V
16 5791-10862-05 J1
Connector, 5-pin Header
17 5791-10862-10 J2,J3
Connector, 1Of-in Header
18 4004-01005-06
Mach. Screw, -40 x
3/8
20 4404-01119-00
Lockwasher Nut, 4-40
Chase Light Assembly
2-27
