A-14046 Disappear Post Assembly
Item Part Number Description
1 AE-26-1200 Coil Assembly
2 10-135
Spring
3 20-8712-43 -E- -Ring, 7l1S-Shaft
4 01-10008
Coli Stop Bracket
5
01-1748-1
Mounting Bracket
6 4006-01005-04 Mach. Screw, #6-32
x
1/4
7 02-4494
Post
8 01-10024
Insulator
9 03-7066-3
Tubing Coil.
1-7/8-
Item Part No.
1 A-11396
2 A-5652-1
a) A-8769
b) 02-2089
3 A-51 03
a) 02-2364
b) 03-8085
c) 20-8716-5
4 12-6227
5 4700-00030-00
8-11395-1
~---{7
===:;y;==r=====r=----(4
51---+1
Skill Shot Kicker Assembly
Description
Kicker Mtg. Bracket Assy
Kicker Crank Assembly
Kicker Crank Sub-Assembly
Pin Cam
Plunger Assembly
Coli Plunger
Armature Link
Roll Pin,
1/8
x
7/16-
Hairpin Clip
Flatwasher,
17/64
x 112x 15ga.
Associated Parts
8-11064-R-1
B-7572-1
01-8-508-S
4006-01017-06
4406-01119-00
AE-24-900
Disappear Post,
Kicker Assembly
Coil
&
Bracket Assembly
Bracket
&
Stop Assembly
Coil Retaining Bracket
Mach. Screw, 6-32 x
3/8
Nut, 6-32 ESN
Coil Assembly
2-20
