C-13174-R
Right Flipper Assembly
Item Part Number
Description
Item Part Number
Description
1 B-13104-R
Flipper Base Assy, R.
21 B-10655-R
Crank Link Assembly, Right
2 03-7811
End of Stroke (EOS) Sw
a)
02-4179
Link Spacer Bushing
3 RM-21-06
Sleeve, Vinyl (Cap. leads)
b)
4010-01086-14 Cap Screw, 10-32 x
7/8,
SH
4 5045-12098-00 Capacitor, 2.2 J.LFd,250V, 20% c)
4700-00023-00 Flatwasher. ,518x
13/64
x 16ga.
5 4701-00002-00 Lockwasher. #6 Split
d)
4701-00004-00 Lockwasher. #10 Split
6 4105-01019-10 Sh. Metal Screw,#5 x
5/8
e)
4410-01132-00 Nut. 10-32 ESNA
7 23-6622
Tape. Double-sided
f)
A-10656
Flipper Link Assembly
8
4008-01079-05 Cap Screw, 8-32 x
5/16
1.) 02-4219
Coli Plunger
9
4701-00003-00 Lockwasher. #8 Split
2.) 20-9370-1
Spring Pin. 5/32 dia. x
7/16
10 01-9375
Switch Mounting Bracket
3.) 03-8050-1
Flipper Link
11 03-7520-2
Ty-Wrap. Nylon
g)
B-10657-R
Flipper Crank Assy, R.
12 20-6516
Speednut. Tinnerman
1.) 01-8073-R
Flipper Crank, R.
13 4010-01·066-06 Cap Screw, 10-32 x
3/8.
SH 2.) 17-1037
Crank Washer
14 4701-00004-00 Lockwasher. #10 Split
3.) 4010-01066-20 Cap Screw,1 0-32 x
1-1/4
15 A-12111
Flipper Stop Assembly
4.) 4410-01127-00 Nut, 10-32 Hex Hd.
16 HW-30018-6
Wire, 18 AWG, Blue
5.) 4700-00107-00 Flatwasher,
5/8
x
13/64
x 12ga.
17 FL-11630
Flipper Coil (Red)
6.) 4701-00004-00 Lockwasher, #10 Split
18 01-7695
Solenoid Bracket
7.) RM-23-06
Tubing, H. S.
1/4
DWP
19 4006-01017-04 Mach. Screw. 6-32 x
1/4
22 23-S5n
Bumper Plug
20 10-376
Coil Plunger Spring
23 03-7568
Flipper Bushing
24 4006-01005-06 Mach. Screw. 6-32 x
3/8
25 4406-01117-00 Nut. 6-32 Hex.
Associated Parts:.
20-9250-5 Flipper Arm on Shaft (White)
23-6519-4 Red Rubber Ring (Red)
Right Flipper
2-14
