Lamp Boards·
(Continued)
A-14025 Face Lamp Assembly
A-14302 3-Lamp Board
Part Number
Description ,
Part Number
Description
5768-12708-00 Lamp PCB
5768-12762-00 Lamp PCB
24-8804
Socket V-Wedge PCB
24-8767
Twist Lamp Socket
24-8768
Bulb #555, (6,3v, 0.25A.)
24-8768
Bulb #555, (6.3v,O.25A.)
5070-09054-00 Diode, lN4004, 1.0A.
5070-09054-00 Diode, 1N4004, 1.0A.
5791-10862-05 ,
Cohr>ector,S-pin Header Sq Post
5791-10871-06 Connector, 6-pin Header Sq Post
A-14303 5-Lamp Board
A-14304 13-Lamp Board
Part Number
Description
Part Number
Description
5768-12763-00 Lamp PCB
5768-12764-00 Lamp PCB
24-8805
Socket H-Wedge PCB
24-8767
Twist Lamp Socket
24-8768
Bulb #555, (6.3v, 0.25A.)
24-8768
Bulb #555, (6.3v, 0.25A.)
5070-09054-00 Diode, 1N4004, 1.0A.
5070-09054-00 Diode, 1N4004, 1.0A.
5791-10869-07 Connector, 7-pin Header Sq Post
5791-10871-10 Connector.10-pin Rat Header
A-14305 4-Lamp Board
A-1441 0 8-Chase Lamp Board
Part Number
Description
Part Number
Description
5768-12765-00 Lamp PCB
5768-12775-00 Lamp PCB
24-8767
Twist Lamp Socket
24-8767
Twist Lamp Socket
24-8768
Bulb #555, (6.3v, 0.25A.)
24-8768
Bulb #555, (6.3v, 0.25A.)
5070-09054-00 Diode, lN4004, 1.0A.
5070-09054-00 Diode, 1N4004, 1.0A.
5791-10871-06 Connector, 6-pin Header Sq Post
A-14412 8-Chase Lamp Board
A-14423-1 Playfield Relay Board
Part Number
Description
Part Number
Description
5768-12778-00 Lamp PCB
5768-12243-00 Lamp PCB
24-8767
Twist Lamp Socket
5010-09534-00 Resistor,
on
24-8768
Bulb #555, (6.3v, 0.25A.)
5070-09054-00 Diode, lN4004, 1.0A.
5070-09054-00 Diode, 1N4004, 1.0A.
5580-12782-00 Relay,12vdc
5791-12273-02 Connector, 2-pin Header
5791-12273-07 Connector, 7-pin Header
C-11998-1 Relay Board
Part Number
Description
5768-12243-00
5010-09534-00
5070-09054-00
5580-09555-01
5791-12273-02
5791-12273-07
Lamp PCB
Resistor,
on
Diode, 1N4004, 1.0A.
Relay, 24vdc, 30A.
Connector, 2-pin Header
Connector, 7-pin Header
Lamp
Boards
2-12
