A..12742..50002 WPC CPU Board
Item Part Number
Ckt Designator
Description
50 10-09034-00
R14-R22, R27-R42, R86,
Resistor, 10m,
1/4w,
5%
A90, R94, R9S
2 50 10-09085-00
A1,R2,R4,R93,R9S,A97
Resistor, 1.5m,
1/4w, 5%
3 5010-09314-00
A52, R54, R56, RSS, AGO,
Resistor, 1.2m,
1/4w, 5%
R62, R64, R66, R75-R82
4 50 10-09358-00
R3, R43-R51, R53, R55, R57,
Resistor, 1KQ,
1/4w, 5%
R59, R61, RSS, R65, R67-R74,
R84
5 50 10-09416-00
R5-RS, R12, R13, R87-R89
Resistor, 470n,
1/4w, 5%
6 50 10-09534-00
VV2, VV4, VV7, VV13·VV18
Resistor, on
7 5010-10258-00
R95,R99
Resistor, .01llfdn,
1/4w, 5%
8 5010-10989-00
R92
Resistor, 470KQ,
1/4w, 5%
9
5010-12104-00
R91
Resistor, 22j.ltd,
1/4w, 5%
10 50 19-09362-00
SIP 1
SIP, 9R, 10-pin, 4.7Kn, 5%
11 5040-08986-00
C31
Capacitor, 100J'td, 10... (±20%)
12 5043-08980-00
B
Capacitor, .01J'fd,
50...,
(+80, ·20%)
13 5043-09030-00
C27
Capacitor, 0.047J'fd, SOv (±20%)
14 5043-09065-00
C3- C26
Capacitor, 470pfd, SOv (±20%)
15 5043-09491-00
C2, C29, C30, C34
Capacitor, 22pfd, 1KV,
(±10"k)
16
5043-09492-00
C28
Capacitor, 100pfd, SOv, (±10%)
17 5043-09845-00
C32, C33
Capacitor, 1KP,
50...,
(±20%)
18 5070-08919-00
02- 018
Diode, 1N4148, 150MA
19 5070-09266-00
01,025
Diode, 1N5817, 1.0A.
20 5160-10269-00
Q1
Transistor, 2N3904, NPN
21 5162-12422-00
U20
IC, ULN, 2803A
22 5281-09308-00
U3
IC, 74LS245, Octal Bus Trncv
23 5281-09486-00
U14
IC, 74LS374, 80 FIF
24 5281-09851-00
U5
IC, 74LS14, SMTITRG
25 5281-09867-00
U1, U2, U7
IC, Octal Buffer, 74LS244
26 5281·10182-00
U11, U12, U13, U15
IC, 74LS240 Driver
27
5284-12651-00
U21
IC,4584
28 5340-12278-00
U8
SJRAM2064
29 5370-12272-00
U16 - U19
IC, LM339, Quad. Comp
30 5370-12687-00
U10
MC, 34064 Reset Chip
31 5520-10438-00
X2
Crystal, 8.0MHz.
32 5520-12084-00
X1
Crystal 32.768 KHz
33 5551-09822·00
L1
ILN, 4.7 UH 3A
34 5671·09019-00
019·021
OSPLLEO RED
35 5700-08985-00
U4
Socket, IC 40P, .S·
3S
5700-12088-00
US
Socket, IC 32P, .6·
37 5700-12424-00
U9
Socket, 84 Pin PLCC
38
5764-12431-00
PC Board
39 5191-10850-00
J201,J204
Connector, 26-pin Header Str Sq.
40 5791-10862-07
J210
Connector, 7-pin Header Str Sq.
41 5791-12461-08
J212
Connector, 8-pin Header Str Sq.
42 5791-12461-09
J206 - J209
Connector,
9-pin Header Sq. pin
43 5791-12461-12
J205
Connector, 12-pin Header Sq. pin
44
5791·12516-00
J202,J211
34' Hen 2x17 STR
45 5881-09021-00
B1 - B3
Battery Holder °AAO
46 5048-11033-00
COO
Capacitor, 0.022j.lf, 10...
47 16-8850-321
PCB Label
48 A-5343-50002-1
U6
Game PROM Assembly
49 5410-12426-00
U9
WPC·89 ASIC
50 5400-10320-00
U4
IC MPU 68B09E
51 5880-09022-00
B1 - B3
Battery, Alkaline,
1.5v (
°AA·)
CPUAssembly
2-6
