Backbox Assembly
o
o
o
o
o
o
o
o
Insert iBoara, Inner
s'uk
'Mew
Item Part Number
Description
Item Part Number
Description
1 01-6645
Venting Screen
9 A-14376-50002
The Machine
Backbox
2 B-10686-1·
Knocker
&
Bracket Assy.
10 01-9047
Insert Stop Bracket
3 A-12497
Upper Insert Bd Hinge Assy.
11 A-13379
Lock Plate Assembly
4 A-14092
Plate
&
Clip Asseni>ly
a)
20-9637
Lock
&
Cam Kit
5 A-12498
Lower Insert Bd Hinge Assy.
12 A-14368
Speaker
I
Display Assembly
6 A-12697-1
Power Driver Assembly
a)
A-14087-1
WPC DisplaylDriver Assy.
7 A-12738-50002 WPC Sound Board
1) A-12739-1
WPC Display Drive Assy.
8 A-12742-50002 WPC CPU Board
b)
5555-12015-00 Speaker, 8Q, 6", 20w
c)
5555-12068-00 Piezo Speaker, 4", SOw.
d)
A-14292-1
Coil
&
Bracket Assembly
*
Refer to Individual Unit's Parts List
Miscellaneous Backbox Parts
Part Number
Description
Backglass Assembly
The.Machine
Backglass
The Machlns
Insert
Hinge Mounting Bracket
Latch -Insert Board
Insert Stop Bracket
Mini Dome - Tr. Red
Egg Crate
A-.!552-50002
31-1357-50002
50002-IN
01-6571
01-6655
01-6652
03-8149-9
03-8519
2-3
Backbox Parts
