Press the Escape button to return to the Presets menu. Then press the Up button to display the next
utility, (or the Downbutton to return to a previous utility).
U.I0 ClearCredits
Press the Enter button to clear the.game Credits. Press the Up button to display the next
utility.
u. n
Auto Burn-in
Press the Enter button to activate Auto Bum-in. This utility allo.wsyou to automatically
cycle through several tests. This helps in finding intermittent problems. The tests that
Auto Burn-in cycles through are the Display 'lest, the Sound and Music 'lest, the All Lamps
Test, the SolenoidTest, the Flashers Test, and the General Illumination Test.
Press the Escape button to return to the Utilities Menu. Then, either press the Up or Down button to
return to a previous Utilities Menu Group, or press the Escape button again to return to the Main
Menu. Once in the Main Menu either use the Up or Down buttons to return to a previous menu
selection,or press the Escapebutton a~ to return to the Attract Mode.
PROBLEM ANALYSIS MESSAGES
The WPC game program has a great capability to aid the operator and service personnel:
At Game Turn-on (and after pressing the Begin Test switch) once the game has been operating for
an extended period, the player score displays may signal with a message, "Press ENTER for Test
Report", that the game program has detected a possible problemwith the game.
To obtain details of the problem, open the coin door and press the Begin 'lest switch. Press
the Enter button to begin displaying the message(s). The followingmessages apply to your
THE MACHINE game.
Check Switch
I..
This message indicates that at least one switch was stuck 'On' at game
turn-on or has NOT been actuated during ball play (for 90 balls or =30 games) by displaying the
message "Adjust Switch
II",
listing each 'problem switch by number. (The game program
compensates the game play requirements affected by each disabled switch to allow 'nearly
normal' play. This helps keep THE MACHINE earning, until the service technician can repair
the problem, bringing the game back to its normal good profitsl)
To verify the problem, refer to the Test Menu text describing Switch Testing, and check each
reported switch using applicable switch tests. Always cheek switch
-operabion
using a ball, to
simulate game conditions. (Switch problems may often be resolved by adjusting the wire switch
actuators, fixing switch circuitry problems, securing loose connectors, etc. Mechanisms using
'opto switches' (drop targets, etc.) need to be checked for proper power connections
(+12V de
and
ground),
Pinball Missing.
THE MACHINE normally uses three balls; however, it will operate
with one or two balls. This message announces that a ball is missing or stuck somewhere. When
the ball is located, return it to the game via the Outhole. Other possibilities for this problem couldbe
malfunctions of the Ball Trough switches or the Ball Shooter switch.
THE MACHINE 1-43
