f..II.r1.t:i.1!J:n.lli
Descrlpllon
1
A-8039-3
Outhole Assembly
2
A-15419
Gear Shift Assembly
3
A-15708
Plunger Kicker
4
C-9638
Ball Release (Trough)
5
A-15205-R-2
Lower Right Flipper
6
12-6466-12
Wireform3"
7
A-14875-2
Right Kicker
a)
B-13935
Coil
&
Bracket Assembly
8
A-15135
Ball Gate
&
Guide
9
A-15127
Disappearing Post (Locker)
10
A-15205-R
Upper Right Flipper
11
A-15103
Wire Right Ramp
12
A-15283
Stop Light Assembly
13
12-6466-14
Wireform
3-1/2"
14
12-6466-9
Wireform
2-1/4"
15
B-9361-R-1
Ball Eject Assembly
16
B-9362-L-2
Coil
&
Bracket Assembly
17
A-13648
Eject Stop Assembly
18
12-7034
Ball Guide Wire
6-39/64"
19
A-15101
Right Ramp
20
A-15301
Accelerator Ramp Assembly
21
A-1390H
Opto Ramp Sw~ch Board Assembly
22
B-12576
Lift Ramp Mechanism
23
B-9362-L-2
Coil
&
Bracket Assembly
24
A-15189
Accelerator Board Assembly
25
12-6466-47
Wire Ball Guide
5-7/32"
26
A-9415-2
Jet Bumper Coil Assembly
27
12-7017
Wire Ball Guide
9-1/4"
28
12-6466-30
Wire Ball Guide
7-1/2"
29
A-15102
Left Ramp
30
A-14875-1
Left Kicker
a)
B-11203-L-1
Coil
&
Bracket Assembly
31
A-15205-L-2
Lower Left Flipper
32
B-11873
Kickback
33
A-14691-5
White Stationary Target
34
A-14691-4
Red Stationary Target
35
A-14691-6
Yellow Stationary Target
36
A-14691-2
Green Stationary Target
37
A-14315
Opto LED Assembly
38
A-14316
Opto Transistor Assembly
Not Shown
A-13204-50004
Bottom Arch Assembly
12-6842
Wire Fence
20-9041
Tinnerman Speednut
20-9045
Instruction Card Cover
16-50004-1
Instruction Card
23-6131-1
Rubber Grommet
31-1008-50004 Screened Bottom Arch
A-15058
Single Flipper Cabinet Sw~ch
A-15060
Double FI"per Cabinet Switch
01-3569-1
Ball Return Runway
03-8661-2
Jet Bumper Playfield Mylar
20-6500
Steel Ball
Playfield Parts
Cabinet shown for reference
THE GETAWAY 2-38
