Coin Door Assembly
A-14148-1
U.S.A. Door with Decals
09-17002-x
2-Chute Door
OQ-17003-x
3-Chute Door
("x· is the country designator)
Item Part No.
Description
Quantity
1
27-1038
Button Cover
2 or 3
2
27-1041-1---.58
Price Panel
2 or 3
3
27-1026-1---.17
Coin Entry Plate
2 or 3
4
27-1016
Lock Assembly
1
5
27-1061-1
Coin Return - Bezel
1
6
27-1062
Coin Return Flap
1
7
27-1021
Button Housing - 2-slot
1
27-1022
Button Housing - 3-slot
1
8
27-1111
Interlock Switch
1
9
27-1006-1
Coin Door, 2-Slot
1
27-1007-1
Coin Door, 3-Slot
1
10
27-1005
Coin Door Frame
1
11
27-1003
MIC
Screw, 6-32 x
3/16
4
12
5641-12724-00
Diagnostic Switch
1
13
27-1101
MIC
Screw,
4-40
x
1/4
2
14
01-9885
Bracket, Diagnostic Switch
1
15
03-7601-4
Button, Red
2
03-7601-7
Button, Black
2
16
27-1078
MIC
Screw, 6-32 x
3/8
2 or 3
17
27-1039
Conical Spring
2 or 3
18
27-1079
Self-tapping Screw, #6 x
1/4
2
19
27-1077-1
Coin box Cover
1
20
27-1066
Slam Switch
1
21
27-1067
MIC
Screw,
4-40
x
1/2
2
22
27-1017
Nut (key)
1
23
27-1012
Locking Cam
1
24
27-1011
Locking Arm
2
25
27-1020
Washer
1
26
27-1018
Star Washer
1
27
27-1019
MIC
Screw,
1/4-28
x
5/16
1
28
27-1089
R-Ring
1
29
27-1083
Retainer
1
30
27-1081
Coin Inlet Chute
2 or 3
31
27-1088
Cable Clamp
2 or 3
32
27-1025
Key Hook
1
33
27-1086
Washer, #6
2 or 3
34
27-1078
MIC
Screw, 6-32 x
3/8
1 or 2
27-1113
MIC
Screw, 6-32 x
7/16
1
35
27-1079
Self-tapping Screw, #6 x
1/4
2 or 3
36
27-1084
Lamp Socket
2 or 3
27-1085
Lamp
2 or 3
37
27-1096
Self-tapping Screw, #5 x
3/8
2 or 3
38
27-1087
MIC
Screw, 6-32 x
5/8
2 or 3
39
27-1082
Lever Arm
20r3
40
27-1097
Switch Cover
2 or 3
41
27-1091-1
Coin Accept Chute
2 or 3
42
27-1075
Wire Form (Small)
2 or 3
or
27-1093
Wire Form (Large)
43
27-1094
MIC
Screw,
4-40
x
7/8
4 or 6
44
27-1087
MIC
Screw, 6-32 x
5/8
4 or 6
45
27-1086
Washer, #6
4 or 6
46
27-1095
Nut,
4-40
ESNA
40r6
47
27-1076-1
Coin Return Box
1
48
27-1078
MIC
Screw, 6-32 x
3/8
2
49
27-1092
Microswitch
2 or 3
THE GETAWAY
2-34
