A-15311
Revolving Flash Lamp Assembly
~ - - - - - ~ - - - -- - - - -- - - - - - - - - - - - - - -- -- - -- - - -- - - - --- - - - -- - -- - - - - - -- - - - -- - - -
6
(J)
2
5
11
Item Part Number
Description
1.
B-10917
Reflector Assembly
2.
B-10934-1
Motor Plate & Bracket Assembly
3.
02-4239
Collar Motor Shaft
4.
03-7520-2
Nylon Ty-Wrap (4 used)
5.
03-7869-1
Snap Bushing
6.
14-7971
Motor 12V, 100RPM
7.
24-8826
Bulb #1156 /12V
8.
4004-01003-05
MS 4-40 x 5/16 P-PH-S (2 used)
9.
4006-01076-04
SS 6-32 x
114
SH-CP
10.
5791-09111-00
3-Position Connector
11.
5820-09080-00
Male Crimp Pin (2 used)
THE GETAWAY 2-25
