A-13088-2 Triac Driver Assembly
o
o
itt
o
o
Part Number
5791-10862-04
5791-10862-05
5791-10862-07
5733-12060-01
5731-09651-00
5131-12543-00
5705-12464-00
5010-09200-00
5010-08930-00
5010-09441-00
5010-09789-00
5045-09795-00
5040-09537 -00
5070-09054-00
5490-09805-00
4004-01005-06
4404-01117-00
4703-00015-00
03-8022-1
Designator
J1
J2
J3
F1
Q1
R1
R2
R3
R4
C1
C2
01
U1
r------
---I
1
1
1-
_j
Description
o
o
••
o
o
o
o
Connector, 4-pin Hdr, Sq Pin
Connector, 5-pin Hdr, Sq Pin
Connector, 7-pin Hdr, Sq Pin
Fuse Holder (F1)
Fuse, 5A, S-8, 250v
Triac ISL, 400V, lOA.
Heatsink
Resistor, 330Q, 2w, 5%
Resistor, 470Q, 1/2w, 5%
Resistor, 100Q, 1/2w, 5%
Resistor, 39Q, 1/2w, 5%
Capacitor, .011lfd, 400V (±1 0%)
Metalized Poly
Capacitor, 100llfd, 100V (±20%)
Diode, 1N4004, 1.0A.
IC, 3030 Triac Driver
Mach. Screw, 4-40 x 3/8
Nut, 4-40 Hex.
Lockwasher, #4 External
Spacer
THE GETAWAY 2-12
