LED List
019 020 021
000
CPU Board
CPU Board
019, Blanking
020, Diagnostic
021, +5vdc
At game Turn-On = 019 & 021 On, 020 Off
During Normal Operation = 019 Off, 020 Flashing, 021 On
o
010
Dot Matrix Controller
Board
IIFS0211
IIFS0111
Dot Matrix Controller Board
010, +5V Circuit, Normailly On
LE07 ~
o
§d
LE03
00
LEO 2
LE06
LE04
0
o
LE01
IIF11511
o
Power Driver Board
II F1071! I F10911
IIF10sIIIF11011
LE05
o
Power Driver Board
LED 1, + 12vdc Switch Circuit, Normally On
LED 2, High/Low Line Voltage Sensor, Normally On
LED 3, High/Low Line Voltage Sensor, Normally Off
LED 4, +5vdc, Digital Circuit, Normally On
LED 5, +20vdc, Flashlamp Circuit, Normally On
LED 6, +18vdc, Lamps Circuit, Normally On
LED 7, + 12vdc, Power Circuit (motors relays etc.), Normally On
The Getaway 1-41
