Press the Escape button to return to the Utilities Menu. Then. either press the Up or Down button
to return to a previous Utility or press the Escape button again to return to the Main Menu. Once
in the Main Menu. press the Up button to move to the next menu selection. the Adjustments
Menu. or press the Down button to return to a previous Main Menu selection.
Press the Enter button to activate the Adjustments Menu. once the menu name is shown under
the Main Menu. Then. use the Up or Down button to cycle through the Adjustments Menu
selections. Press the Enter button to activate the desired adjustments group when it appears in
the display.
When an adjustment is activated. the setting value begins to flash. Use the Up or Down button to
raise or lower the setting value. When the desired value is displayed press Enter to lock in the
value. If you realize you have made an error. press the Escape button while "Saving Adjustment
Value" is displayed. The new value is ignored and the original value is retained.
A. Adjustment Menu
A.1 Standard Adjustments
A.2 Feature Adjustments
A.3 Pricing Adjustments
A.4 H.S.T.DAdjustments
A.5 Printer Adjustments
(optional board required)
A.1 Standard Adjustments
A.l
01
Balls Per Game
The operator defines a "game" by specifying the number ,ofballs to be played.
The range of this setting is 1 through 10.
A.l
02
Tilt Warnings
The operator specifies the number of total actuations of the plumb bob
mechanism that can occur before the game is "tilted". The range of this setting
is 1 through 10.
A.l
00
Maximum Extra Balls
The operator chooses the number of Extra Balls that a player may accumulate.
The range of this setting is 1 through 10. or "No Extra Ball" (extra ball disabled),
A.l
Maximum Extra Balls/Ball in Play
The operator chooses the number of Extra Balls to be awarded per ball in play.
The range of this setting is:
Off
1-10
No maximum number of Extra Ball per ball in play.
1 through 10 Extra Balls per ball in play.
A.l
Replay System
The operator chooses the replay system to be used. The choices are:
Fixed -
Replay value is set by the operator and does not change during
game play.
Replay starting value is set by the operator and change every 50
games to comply with the percentage of replays desired.
Auto%-
The Getaway 1-25
