Press the Enter button to activate the Test Menu, once the menu name is shown under the Main
Menu. Then, use the Up or Down button to cycle through the Test Menu selections. Press the
Enter button to activate the desired test when that test appears in the display.
T. Test Menu
T.I
T.2
T.3
T.4
T.5
T.6
T.7
T.S
T.9
T.IO
T.II
T.12
T.13
Switch Edges
Switch Levels
Single Switch
Solenoid Test
Flasher Test
General Illwnination
Sound
&
Music Test
Single Lamps
All Lamps
Lamp
&
Flasher Tests
Display Test
Supercharger Test
Supercharger Time Test
The entire switch matrix is displayed on the left side of the display. It shows the state of ALL
switches. A dot indicates the switch is open. A square indicates the switch is closed. Also, the
numbers assigned to each switch indicate where the switch is located in the matrix. The number
on the left indicates the column, the number on the right indicates the row. Example- Switch 23
means 2nd column, 3rd row.
A short to ground - on either the row or column wire - appears as a shorted row(s). However. a
column wire shorted to ground disappears when all of the indicated row switches are open. A row
wire shorted to ground does not disappear.
A shorted diode in the switch matrix can cause other switches to appear closed.
These
"phantom" switches (though not actually closed), complete a rectangle in the switch matrix.
Therefore, if two switches in the same column are closed (example; #22 and #24), and a third
switch is pressed in another column but in the same row as one of the first two (example; #32),
the "phantom" switch #34 is falsely indicated as closed . The switch with the shorted diod e is
diagonally opposite the "phantom" switch (in this case #22).
T.I Switch Edges
To activate the Switch Edges Test, from the Test Menu, press the Ent er button . Press each switch
one at a time. The name and number of the switch is shown in the display. If a switch other then
the one pressed, or no switch at all is indicated. the system has detected a problem with the
switch circuit.
Press Escape to return to the Test Menu. Press the Up button to display the next test. (or the Down
button to return to a previous test) . Press the Enter button to activate that test .
T.2 Switch Levels
Once the test name is shown under the Test Menu. press the Enter button. This test automatically
cycles through all switches that are detected closed. The name and number of each switch that is
detected is shown in the display . A filled square indicates the switch position in the matrix ,
Press the Escape button to return to the Test Menu. Press the Up button to display the next test.
(or the Down button to return to a previous test). Press the Enter button to activate that test.
The Getaway 1-13
