Pinball Game Assembly Instructions
'&'CAUTION
After assembly and installation at its site location. this game must be plugged Into a properly
grounded outlet to prevent shock hazard. and to assure proper operation. DO NOT use a 'cheater'
plug to defeat the ground pin on the line cord. DO NOT cut off the ground pin.
The Getaway is a three ball game.
1. Remove all cartons, parts, and other items from the shipping container, and set them aside.
2. Place the cabinet on a support and attach rear legs using leg bolts. Leg levelers and leg bolts are
provided among the parts in the cash box.
3. Attach the front legs (after installing leg levelers). using leg bolts.
/-. •...
I
i
I
I
.. . . .
\
I
/
... ..\
/
/........ ..
\
/
t,... •••..
./
Detail View -
Leg Leveler
1 ...../
,,/
.......
/
"
/( rr-/~-
- ---I
\ 1/
I
-~... . .
I
t<;:---..:--:::::= -
,
Approx Playfic1d
Pitch Angle:
,
~
6 - 7 Degrees
Nut
'.
4422-01117-00
See Detail View :
I
\
I
'"
'
--'
(-10843
.~"""",,~-!-
0 Degrees
Leg
:::1-"=-11-
08-
7377Leg
Leveler
~--IIl-Shaft
}
FootPad
/
===
4. Reach into the cabinet and backbox and ensure that the interconnecting cables are not kinked
or pinched. Be careful to avoid damaging wires at any stage of the assembly process.
5. Raise the hinged backbox upright and latch it into position. Unlock the backbox, and remove
the backglass. Remove the shipping block holding the Insert Board. Unlatch and open the Insert
Board. Carefully lift up the Speaker Panel and lay it down on the playfield glass . (Be careful not
to damage the Dot Matrix Display /Drtver.) This allows access to the bolt holes used for securing
the backbox upright . To secure the backbox, install the washer-head mounting bolts through the
bottom holes of the backbox into the threaded fasteners in the cabinet. Close and latch the Insert
Board. Replace the Speaker Panel. Reinstall the backglass, and lock the backbox.
&
CAUTION
FAILURE
TO INSTALL
the backbox mounting hardware properly can cause personal injury.
NEVER TRANSPORT
a pinball game with the hinged backbox erect. Always lower the backbox
forward onto the playfield cabinet on a layer of protective material to prevent marring or
damage and possible personal injury.
The Getaway 1-2
