Opto Ramp Switch Board Assembly
sr
9r
I
R5
I
R6
R7
+
<-
-
0
[j
am
0
~?5
@~~~~I
0
CQID
0
am
-
CQ!J)
0 0
BE
J3
EJE
J4
BE
J2
1000_0
liDo_Do
110_0001
Jl -
1
Black (Ground) from Power Driver Board Jl16-3
Jl -
2 Gray-Yellow (+12V) from Power Driver Board Jl16-2
Jl -
3 N/C
Jl -
4
N/C
Jl -
5 White-Green (Switch Row #5) from CPU Board J209-5
Jl -
6 White-Yellow (Switch Row #4) from CPU Board J209-4
Jl -
7 Green-Gray (Switch Column #8) from CPU Board J206-9
J2 -
1
Black to Switch # 84 Opto LED
J2 -
2 Red to Switch #84 Opto LED
J2 -
3 Green-Yellow to Switch #84 Opto Transistor
J2 -
4
N/C
J2 -
5 White-Yellow to Switch #84 Opto Transistor
J3 -
1Black to Switch #85 Opto LED
J3 -
2 Red to Switch #85 Opto LED
J3 -
3 Green to Switch #85 Opto Transistor
J3-4N/C
J3 -
5 White-Green to #Switch 85 Opto Transistor
J4 through J7 are Not Used
