A-15189
Accelerator Board Assembly
'-
r-o
C4
o
(]I])
R
CQTI)
CQID
CQTI)
z>
C20
o
@TI)
R45
RH
R5
0
RS
-m:D-
R7
--{[ill-
R8
---{]D-
--mD-
o
*
o
o
o
J4
o
o
o
*
o
o
o
o
=
=
=
=
o
o
o
~I
I
I
*
o
o
o
=
~J
o
J5
J1 -1 Gray-Yellow (+12V) from Power Driver Board J118-2
J1 - 2 Gray-Yellow (+ 12V) loop from J1-1
J1 -
3
N/C
J1 - 4 Black (Ground) from Power Driver J118-3
J2 -
1
N/C
J2 - 2 White-Orange (Switch Row #3) from CPU Board J209-3
J2 -
3
White-Red (Switch Row #2) from CPU Board J209-2
J2 - 4 White-Brown (Switch Row #1) from CPU Board J209-1
J2 -
5
N/C
J2 -
6
Green-Gray (Switch Column #8) from CPU Board J206-1
J4 Not Used
J5 - 1 Red to Switch #81 Opto LED
J5 - 2 Green -Brown to Switch #81 Opto Transistor
J5 -
3
Black to Switch #81 Opto LED
J5 - 4 White-Brown to Switch #81 Opto Transistor
J5 - 5 Red to Switch #82 Opto LED
J5 - 6
N/C
J5 -7 Green-Red to Switch #82 Opto Transistor
J5 - 8 Black to Switch #82 Opto LED
J5 - 9 White-Red to Switch #82 Opto Transistor
J5 - 10 Red to Switch #83 Opto LED
J5 - 11 Green-Orange to Switch #83 Opto Transistor
J5 - 12 Black to Switch #83 Opto LED
J5 - 13 White-Orange to Switch #83 Opto Transistor
J6 -
1 Violet-Green (Power) to Solenoid #25
J6 -
2 Violet-Green (Power) to Solenoid #26
J6 -
3
Violet-Green (Power) to Solenoid #28
J6 -
4
N/C
J6 -
5
Brown (Drive) to Solenoid #25
J6 -
6
Red (Drive) to Solenoid #26
J6 -7
Orange (Drive) to Solenoid #28
J7 -
1 Violet-Green (Power) from Power Driver Board J1 07-1
J7 -
2
N/C
J7 -
3
Black (Ground) from Power Driver Board J131-1. 4
J7 -
4
Black (Ground) from Power Driver Board J131-1. 4
J8
-1Blue-Brown (Enable) from Power Driver Board J122-1
J8 -
2
Blue-Yellow (Enable) from Power Driver Board J122-4
J8 -
3
N/C
J8 -
4
Blue-Red (Enable) from Power Driver Board J 112-4
J8 -5
to
J8 -
7
N/C
