Page 114 - The Getaway

Flashlamp Circuit
DRIVE POWER
Power Drtwr Board Power Drtver Board
The Microprocessor toggles the output of the 74LS374. When point "A" is low, point "B" the collector of
the 2N5401 transistor is high. Once point "B" is high, point "C" the collector of the TIPI02 transistor is
low. When Point "C" is low the flashlamp is grounded through the transistor and the flashlamp turns On.
When point "A" toggles high the circuit shuts Off.
General Illumlnatfon
DRIVE POWER
To
CPU
Board
1---1
J12 1 1Jl20
xl IXf--~
1 1
I _!ackbo~ I
JllS
Powu~Board Power Driver Board
To
TranaCormer
Sooondary
MlcroprottSS j-----__'
or
ICPU Boanll
Zen>
era ••
5 volt secondary Detection
Clr<:Ult0-.,.
Drtver
Board) Block Diagram of General Illumination Circuit
When point "A" toggles low, then potnts "B" and "C" are high. This turns On the triac and the
desired General Illumination string lights.
The Getaway 3-9
