Ball Popper
&
Opto Assembly
(~)-----~
I
-
(~)
---------(~
____---_._-.--(5)-
-
..
'----.
Item
Part
No.
Description
Item
Part No_
Description
1-
4106-01019-06 sh. Metal Screw, #6x3/8"
B_ 03-8561
Photo Transistor Assembly
2.
400B-01017-04 Mach. Screw, 8-32 x
1/4"
9_
4106-011 52-06 Coil Tubing
3_ AE-23-800
Coil Assembly
10.
A-16909
Bracket, Ball Popper
4_
10-135
Spring
11_ 03·7067-5
Rubber Grommet
5_ 02-4668
Armature Assembly
12.
A-15914
LED Assembly
6.
01-9794
Mounting Bracket
13.
23-6420
Ball Popper Cup
7.
H-17609-4
opto Switch Cable
14.
A-1690B
Sh. Metal Screw, #6-32 x 3/8"
2-20
