A-1875.3
Outhole Ball Trough Assembly
C~)----.
Ci)-- ---
Item Part No.
Description
t.
A-16809-2 Ball Trough Welded Assy.
2.
01-11587
Ball Trough Front
3.
A-6306-2
Bell Armature Assembly
4.
AE-26--1500 Coil Assembly
5.
01-a-sOa·T Solenoid Assembly
6.
03-7067-5 Coil Tubing
7.
10-135
Spring
8.
23-6420
Rubber Grommet
9.
03-8523
Insulator
10.
01·11586
Coil Mounting Brk!. (Bell)
Associated Assemblies:
(Not Shown)
A·15576
H-18757
H-i8758
7-Switch
octo
Board
7 Opto Trough Cable, Input
7 Opto Trough Cable, Output
/
!
/
(~/
/
5
Item Part No.
Description
1'.
12.
13 .
14 .
15.
16.
17.
18.
19.
20 .
4008-01017-05
4408-01119-00
4008-01 017-06
23-6702
A-18S17
A-18618
4006·01003·10
23-6626
4700 -00004-00
02-4975
Mach. Screw, 8-32 x
5/16"
Nut 8-32 ESN
Mach. Screw, 8-32 x
3/8 '
Bumper Plug
Trough 7 IRED PCB Assembly
Trough 7 IR TSTR PCB Assy.
Mach. Screw, 6-32 x 5/8" SEMS
Grommet
Flatwasher,
9/64
x
7/16 x 219a.
Bushing
2-17
