12.
Install full playfieJd mylar,
if
desired.
NOTE:
The playfield is coated with a special hardcoat surface
and
does not require a protective mylar. However, mylars can be purchased through your local
Williams Distributor. Specify part number 03-9251-1 for full playfield mylar.
13.
Clean and reinstall the playfield cover glass. Prepare the game for player operation.
14.
To attach the line cord, remove the envelope stapled
10
the inside of the cabinet (near the cash
box). Remove the four Phillips-head screws that mount to line cord cover plate to the rear cabinet.
Match the prongs on the plug with the holes in the receptacle. and push the line cord securely into
place. Make sure the cord is aligned with the indentation on the cover plate (indentation should
point toward bottom of the cabinet).
Remount line cord cover plate.
If
desired, tour tamper
resistant screws have been provided in an envelope marked "Security Screws" (located in the cash
box) to remount cover plate.
(Part of cabinet shown
for reference only)
Receptacle
1-4
