A-15472-1
Fliptronic II Board Assembly
U
~r---J90-3---'I~
E;:
OJ
S
1
1
I
c>
(> (>
0 0 0 0
<>
(>
*
(> <> (>
1
13
J!102
r--
••
0
*
<)
•..
e
~
••
<>
0
~
..
J901-1 White-BluB,
50Vac from Power Driver 8rd J104·2
J901-2 While-BIUII. SOVa<: lOOpgrom J901·1
J901-3 White-Slue, SOVac from Power Driver Srd J104·'
J901·4
WC
J90I-5 White-Blue, SOVa<: loop from J901·3
J902-1 Orange-Gray,
sot. 36, Up/Down Gate Left
J902-2
WC
J902-3 Yellow-Gray.
SOl,
35, Up/Down Gate Right
J902-4 Oran9G-ViOlet. holding. upper right !lipper coil
J902-S N/C
J902-6 Yelfow-Violet. power, upper right flipper coil
J902-7 Orange-elUe,
holding. lower lett flipper coil
J902·8
NlC
J902-9 Yellow·Slue,
power. lower left flipper eoil
J902-10
WC
J902·11
Orange-GreM. hOlding, lower right flipper
coil
J902-12
we
J902-13 Yellow-Gteen. power. lower right flippet coil
J903. 34-pin ribbon cable, data toft rom J202; J60t; Pl
J904·1 Gray. -+5V from Power Driver BoardJ114·3.4
J904-2 Gray·Gree-n,
.12V
from Power Driver Btd J114·1.2
J904-3
NlC
J904-4
Stack.
ground kom Power Driver BId J1 14·5,7
J904-5
Brack,
ground from Power Driver Srd
J114·S,7
J905-1
Blue.violet.
F2 to right flipper 01'10switch brd J1·1
J905-2 Blue-Gray, F4 to left flip(:)Eropto SWitch bfd J1-'
J905-3 Black·Yeliow. F6
to righlllipper opto
switch brd J1-2
J905-4
NlC
J905-5 Black-Blue, F8 10 left flipper opto switch bfd JI-2
J905·6 Orange. ground to left flipper opto switch
bed
J
1-3
J906-1 Black-Green, F1 to lower right end-of·stroke switch
J906-2
WC
J906-3 Slack-Blue. F3 10 lower left end-cf-stroke $Witch
J906-4
Stack.vio!et F5 to
upper right end-of·stroke switch <not used)
J906-5 Black-Gray. F7 to upper left end-ot-stroke switch
J906·6 Orange. ground
to
end-ot-stroke
switcnes
J907·1 Red-Green, +50V to lower
right
flipper
coil
J907-2 Red-Green. +5()V loop from J907-1
J907-3 8/C
J901-4 Red-e!uE!. +SOV to lower lelt flipper coil
J907·5 Red-Blue. +SOV loop from J907-4
J907·6
Red.violet.
+50V
to upper
right flipper
coil
J907·7 Red-Viole!. +50V loop from J907-6
J907-8 Red·Gray. +SOV 10 upper left flipper coil
J907·9 Red-Gray +50V loop trern J907-8
3·28
