COIN DOOR ASSEMBLY
USADoorwith
decala.
pIn C-13155-1
2-Chute Door -
09-17002-z
3-Chute Door -
09-17003-z
r'z"
is the country designator)
Item
Part Number
ne.cription
Quantity
1 27-1038
Button Cover
2or3
2 27-1041-1-54
Price Panel
2or3
3 27-1026-1-15
Coin Entry Plate
2or3
4 27-1016
Lock Assembly
1
5 27-1061-1
Coin Return - Bezel
1
6 27-1062
Coin Return Flap
1
7 27-1021
Button Housing - 2-slot
1
27-1022
Button Housing - 3-slot
1
8 27-1111
Interlock Switch
1
9 27-1006-1
Coin Door. 2-Slot
1
27-1007-1
Coin Door. 3-Slot
1
10 27-1005
Coin Door Frame
1
11 27-1003
M/CScrew.6-32x3/16
4
12 27-1008
Diagnostic Switch
1
13 27-1101
M/C Screw. 4-40 x 1/4
2
14 27-1102
Bracket. Diagnostic Switch 1
15 27-1037
Button
2or3
16 27-1078
M/C Screw. 6-32 x 3/8
2or3
17 27-1039
Conical Spring
2or3
18 27-1079
Self-tapping Screw. #6x 1/4 2
19 27-1077-1
CoInbox Cover
1
20 27-1066
Slam Switch
1
21 27-1067
M/C Screw. 4-40 x 1/2
2
22 27-1017
Nut (key)
1
23 27-1012
Locking Cam
1
24 27-1011
Locking Arm
2
25 27-1020
Washer
1
26 27-1018
Star Washer
1
27 27-1019
M/C Screw 1/4-28 x 5/16
1
30 27-1112
Coin Inlet Chute
2or3
31 27-1088
Cable Clamp
2or3
32 27-1025
Key Hook
1
33 27-1086
Washer. #6
2or3
34 27-1078
M/C Screw. 6-32 x 3/8
lor2
27-1113
M/C Screw.6-32x 7/16
1
35 27-1079
Self-tapping Screw. #6 x 1/4 2or3
36 27-1084
Lamp Socket
2or3
27-1085
Lamp
2or3
37 27-1096
Self-tapping Screw. #5 x 3/8 2or3
38 27-1087
M/C
Screw. 6-32 x
5/8
2or3
39 27-1082
Lever Arm
2or3
40 27-1097
Switch Cover
2or3
41 27-1091-1
Coin Accept Chute
2or3
42 27-1075
Wire Form (small)
2or3
cr
27-1093
Wire Form (large)
43 27-1094
M/C Screw. 4-40 x 7/8
4or6
44 27-1087
M/C Screw. 6-32 x 5/8
4or6
45 27-1086
Washer. #6
4or6
46 27-1095
Nut. 4-40 ESNA
4or6
47 27-1076-1
Coin Return Box
1
48 27-1078
M/C Screw. 6-32 x 3/8
2
49 27-1092
Microswitch
2or3
Coin Door
2-23
