1 Bank Drop Target Assembly
pIn
C·13312·4
Item Part No.
Description
\
~
1
03-8033
Target
\
2
B-11213
Target Sub-assembly
\
3 4408-01119-00 Nut 8-32 ESNA
4
A-11397
Stop Bracket Assembly
5
AE-23-800
Coil Assembly
6
01-8413
Coil Mtg. Bracket
f-
7
A-11388
PI.
&
Reset PI. Assy
8 4008-01016-10 M.S. 8-32 x 5/8 P-RH
9
20-8712-25
liE" Ring 1/4 Shaft
10
10-364
Extention Spring
(not shown)
11 4700-00016-00 Washer
12
C-1331-L
1 Bank Opto Assy
13
10-392
Compression Spring
14
20-7812-18
liE" Ring 3/16 Shaft
15 4700-00072-00 Washer
16
23-6626
Grommet
17
03-7066-4
Tubing
\
Bell Assembly
pIn
C·8461·1
-,
"
Item Part No.
Description
'\
1
B-8459
"M" Mtg. Relay Frame Assy
2
B-8460
Bell & Mtg. Plate Assembly
3
B-8462
Armature Assembly
<,
SM-26-600
Coil Assembly
I
4
/
5
SW-10A-52
Bell Switch
/
/
6
10-362
Extention Spring
7
20-6516
Speed Nut
8 4006-01003-04 M.S. 6-32 x
1/4
P-PH-$
9 4008-01021-07 M.S. 8-32 x
7/16
P-RH-BR
10 4105-01001-14 S.M.S. 5 x 7/8 P-PH
11 4700-00089-00 .172 x
7/16.062
BA.
12 4701-00003-00 8 Split
13
HW-30122-4 22 Gage Jumper Wire
14 5043-09072-00 .01 IlFD Capacitor Cer. Disc
(not shown)
2.20
Bell & Drop Target
