Maintenance Information
• Ball Shooter Lane Feeder
Figure 5 shows the two main lubrication points of the Ball Shooter
Lane Feeder. The shaded arrows show the directions in which the Ball
Shooter Lane Feeder and other parts of its related assemblies can be
adjusted for proper operation. Note that there are mechanisms quite Similar
to this Assembly: they have the same lubrication requirements and
adjustment capabUities as the Ball Shooter Lane Feeder.
TOP VIEW
LUBE
PCINTS
Figure 5. Adjustments and Lubrication POints, Shooter Lane Feeder
• Left
&
Right Kickers
Because of the functional design (arm-actuated via solenoid plunger
operation), the pivot points of the Left and Right Kickers ("Slingshots")
all require lubrication as a regular servicing procedure. Mechanical
adjustments are simple and somewhat similar to the Ball Shooter
Lane Feeder. These mechanisms should also be checked for proper fit
(snugly tight) where they attach to the playfield.
Maintenance Information 1-45
