Game Control Locations
Figure 2 shows the locations of the following SWitches. except for the last two (CPU
and Sound Diagnostic switches. which are shown in the Circuit Board Locations
Diagram).
THE ON-OFF SWITCH
is on the bottom of the cabinet near the I1ght front leg.
THE VOLUME CONTROL
is on the left inner wall of the cabinet on the tilt mechanism
board. It is accessible
by
opening the coin box door.
THE CREDIT SWITCH
is a pushbutton to the left of the coin door on the cabinet
exterior.
GAME ADJUSTMENT/DIAGNOSTIC SWITCHES.
GAMESHOWallows the operator to
control all game adjustments, obtain bookkeeping information, and diagnose
problems, using only three switches mounted on the inside of the coin door, along
with the Credit button beside the coin door.
ADVANCE, AUTO-UP/MANUAL-DOWN,
and
HIGH-SCORE RESET
are the SWitches
located on the inside of the coin door. Refer to the text. discuSSing Game Status
Displays and the Test/Diagnostic Procedures for details cencemmg bu tton
operation.
THE MEMORY PROTECT SWITCH
is on the inside frame of the coin door. This Interlock
switch must be open to clear bookkeeping totals and to make game adjustments.
It
automatically opens. when the coin door opens.
On the previous page, the Circuit Board Locations Diagram shows the location of
the CPU Board switch Oeft edge of CPU Board, Backbox: View).
THE CPU DIAGNosnC SWITCH
(SW2) is near a large.
socketed microprocessor chip.
This Switch initJates the
Memory Chip Test explained
in the Test/Diagnostic
Procedures.
,
"
On-Off Switch
Figure 2. Control Locations
1-4 Control Locations
