SWITCH LOCATIONS
~
~
lwn
~
~
OggilUigD
11-12
Not Used
13
20-9663-1
Start Button
14
20-6502-A
'Plumb Bob lilt
15
5647-09957-00
B-8925
Left Trough
16
5647-09957-00
B-8925
Center Trough
17
5647-12693-08
A-I 1680
Right Trough
18
5647-12133-12
A-I0417
Outhole
21
27-1066
'Slam Tilt
22
A-8630
'Coin Door Closed
23
Not Used
'Ticket Opto.
24
A-8630
•Always Closed
25
5647-12693-19
A-I 2688
Right Flipper Lane
26
5647-12693-19
A-12688
Right Oudane
27
5647-12693-04
A-11619
Ball Shooter
28
Not Used
31
SW-IIA-37
B-12030-2
Upper Left Jet
32
SW-IIA-37
B-12030-2
Upper Right Jet
33
SW-11A-37
B-1 2030-2
Center Left Jet
34
SW-11A-37
B-1 2030-2
Center Right Jet
35
SW-lIA-37
B-12030-2
Lower Jet
36
SW-IA-114
B-8284-1
Left Slingshot
37
SW-IA-120
A-1I539-1
Right Slingshot
38
5647-12693-19
A-12688
Upper Left Loop
41
B-1 1696-1
Grave "Go
42
B-1 1696-1
Grave'R"
43
5647-12693-25
A-14962
tChair Kickout
44a
B-1 1696-4
Cousin It (2)
b
B-12583-4
(2)
45
B-11696-15
Lower Swamp Million
46
Not Used
47
B-11696-15
Center Swamp Million
48
B-1I696-15
Upper Swamp Million
51
5647-12693-19
A-I 5372
Shooter Lane
52
Not Used
53
A-15017/A-15018 Bookcase Opto 1
54
A-15017/A-150l8 Bookcase Opto 2
55
A-15017/A-15018 Bookcase Opto 3
56
A-15017/A-15018 Bookcase Opro 4
57
A-14231/A-14232 Bumper Lane Opto
58
5647-12693-21
A-14972
Right Ramp Exit
61
5647-12693-11
A-14492
Left Ramp Enter
62
B-1I696-5
Train Wreck
63
5647-12693-19
A-12688
Thing Eject Lane
64
5647-12693-11
A-13627-2
Right Ramp Enter
65
5647-12693-21
A-I 5047
Right Ramp Top
66
5647-12693-21
A-15047
Left Ramp Top
67
5647-12693-19
A-12688
Upper Right Loop
68
5647-12693-08
A-I 5070
Vault
71
5647-12693-25
A-I 4964
tSwamp Lock Upper
72
5647-12693-25
A-I 4964
tSwamp Lock Center
73
5647-12693-25
A-14964
tSwamp Lock Lower
74
5647-12693-25
A-I 4964
tLockup Kickout
75
5647-12693-19
A-12688
Left Outlane
76
5647-12693-19
A-I 2688
Left Flipper Lane 2
77
5647-12693-25
A-I5200
tThing Kickout
78
5647-12693-19
A-12688
Left Flipper Lane I
81
5647-12693-08
A-I 4970
tBookcase Open
82
5647-12693-08
A-14970
t
Bookcase Closed
83
Not Used
84
A-I5285
tThing Down Opto
85
A-l5285
tThing Up Opto
86
B-12583-1
GRAVE "A"
87
5647-12133-11
A-9381-R
Thing Eject Hole
88
Not Used
• Not shown.
t
Located on underside of playfield.
The ADDAMS FAMILY
2-39
