A·15200 Kickout Assembly
3
D
Item PartNo.
1.
A·15201
2.
03·7067
3.
AE·23·800
4.
01-9423
5.
4408-01119-00
6.
10-135
7.
A-13270
8.
23-6420
9.
5647·12693·25
10.
4002-01105·07
11.
5070-09054-00
12.
01-8240
13.
A·15376
14.
4008-01003·06
15.
01-8600
Description
Kickout Sub-Assembly
Coil Tubing
Coil Assembly
Coil Bracket Assy.
Nut 8-32 ESN
Solenoid Spring
Bell Armature Assembly
Rubber Grommet
Switch
Mach. Screw, 2-56 x 7/16P-PH-S
Diode 1N4004
Nut Plate
Coil Bracket - Front
Mach. Screw, 8-32 P-PH-S
Insulator
The ADDAMS FAMILY 2-26
