GAME CONTROL LOCATIONS
Cabinet Switches
The On-Off switch is located on the bottom of the cabinet near the right front leg.
The Start Button is a pushbutton to the left of the coin door on the cabinet exterior. Press the
Start button to begin a game, or during the diagnostic mode, to ask for HELP.
Coin Door Switches
The operator controls all game adjustments, obtains bookkeeping information, and diagnoses
problems, using only four pushbutton switches mounted on the inside of the coin door. The
Coin Door Switches have two modes of operation Normal Function and Test Function.
Normal Function
The Service Credits switch puts credits on the game that are not included in the game audits.
The Volume Up switch raises the sound level of the game. Press and hold the button until the
desired level is reached.
The Volume Down switch lowers the sound level of the game. Press and hold the button until
the desired level is reached. See Adjustment A.I 28 to shut sound Off completely.
The Begin Test switch starts the Menu System Operation and changes the Coin Door Switches
from Normal Function to Test Function.
Test Function
The Escape switch allows you to get out of a menu selection or return to the Attract Mode.
The.1lp. switch allows you to cycle forward through the menu selections or adjustment choices.
The Down switch allows you to cycle backward through the menu selections or adjustment
choices.
The
Enw:
switch allows you to get into a menu selection or lock in an adjustment choice.
Coin Door Switches
The ADDAMS FAMILY
1-4
