PINBALL GAME ASSEMBLY INSTRUCTIONS
THE ADDAMS FAMILY IS A 3 BALL GAME.
Weight: 290 Lbs.
Width: 26" Approx.
Length: 55" Approx.
Height: 85" Approx.
1.
Open the shipping container; remove all cartons, parts, and other items, and set them aside.
2. Place the cabinet on a support and attach rear legs using leg bolts. Leg levelers and leg bolts
are provided among the parts in the cash box.
3. Attach the front legs {after installing leg levelers}, using leg bolts
See
diagram below ..
F> ,
I
I
I
I
••..,
I
I
....,
I
I ••.."
,
I
I"
\
I
1'''
••..
"
"
"
I
••..I
••..
<....
rJ---?£-----1
1\1/
••.." ...
1
•..~k......
1
--------
__
1
Detail View-
Leg Levder
..
, ,
\
See Detail View :
I
"
"
"_,,
C-10843-1
Leg
08-7377
Leg Leveler
Nut
4422-01117-00
Pinball Assembly, Playfield Pitch Angle, and Leg Leveler Details.
4. Reach into the cabinet and backbox and ensure that the interconnecting cables are free to move
{not kinked or pinched}.
Be
careful to avoid damaging wires at any stage of the assembly
process.
&.
CAUTION
FAILURE TO INSTALL
the backbox mounting hardware properly can cause personal injury.
NEVER TRANSPORT
a pinball game with the hinged backbox erect. Always lower the
backbox forward onto the playfleld cabinet on a layer of protective material
[0
prevent marring
or damage and possible personal injury.
The ADDAMS FAMILY 1-2
