IV. GAME REGISTERS & OPTIONS
BOOKKEEPING DATA
Total Coins
Number of coins thru chutes 1, 2,
&
3
Game Percent
Percentage of replays
Coins Chute 1
#:
of coins thru chute
1
Coins Chute
2
#:
of coins thru chute
2
Coins Chute 3
#:
of coins thru chute 3
Bonus Credits
Number of Bonus Credits Given
Total Plays
Number of plays both paid and replays
Total Replays
Number of awarded games
Service Meter
Total
#:
of service credits
Game Credits
Current game credits-Enter
0 thru
5
Added to Service Meter
NQt
added to current Game Credits.
Special Meter
Total
1;1
of Playfleld SpeCiafs awarded
Clear Sooklng
To clear bookkeeping press
"65"
then "Enter"
SELF·TESTING
Single Lamp
All Lamps
Display
Solenoid
Single Solenoid
Sound
Game Rom
1.0.
Switch Test
Steps one lamp at a time, and Connector
1.0.
Press "A" to advance, "S" to backup, and "C" to cycle
All lamps light alternately, 1st "A" phase then "B"
Steps thru alphanumeric character set
Fires one driver at a time, and Displays Driver and Connector
1.0.
Fires one driver at a time. Press A for same solenoid
B for next
Plays game sounds
Displays your Rom or Roms
1.0.
Displays stuck switch by description
PRESS TEST BUTTON ON DOOR
TO
EXIT SWITCH TEST
PERCENT DATA VALUES
Game Percent
Total Plays
Game Time
Total Replays
Threshold 1
Threshold 2
Threshold 3
Timed Special
Hiscore Beaten
Extra Balls
Timed X-Balls
Hold Bonus
Strange Science
Outlans Special
Anti-Gravity
Particle Separator
Brain Transfer
Load Ball
Unload Ball
All Load
Mu Iti-Release
PERCENT OPTIONS
Threshold 1
Self Percent
Target Percent
Threshold 1 Percent
Threshold 2
Threshold 3
Highest Score
Percentage of replays
Number of plays both paid and replays
Total number of minutes
Total number of replays
#
of times the first threshold was beaten
#
of times the second threshold was beaten
#
of times the third threshold was beaten
1;1
of timed Specials awarded by completing each Outlane
Total number of times the high score was beaten
1;1
of non-timed extra balls that were awarded
1;1
of timed extra balls that were awarded
1;1
of times Hold Bonus was awarded
1;1
of times S-T-R-A-N-G-E S-C-I-E-N-C-E was completed
1;1
of non-timed Specials awarded by completing each Outlane
1;1
of times Anti-Gravity was completed
1;1
of times Particle Separator was completed
1;1
of times Brain Transfer was completed
1;1
of times each ball was loaded in Atom Smasher
#
of times each ball was unloaded from Atom Smasher
1;1
at
times all 5 bails were loaded in Atom Smasher
1;1
of times a ball was loaded during Multi-Ball play
Enter 0 thru
9,999,999;
sets award level and display
Enter 0 or
1;
0 disables Self-Percentaging Process.
1 enables Self-Percentaging Process
Enter desired percentage of replays awarded tor reaching Threshold 1,
Displays actual percentage of replays awarded reaching Threshold
t,
Enter 0 thru
9,999,999;
sets award level and display
Enter 0 thru
9,999,999;
sets award level and display
Enter 0 thru
9.999,999;
sets the HiScore replay level
FACTORY SETTINGS
1,500,000
1
10
Unchanged
3,500,000
00
5,555,555
BASIC OPTION VALUES
Credit limit
Enter 1 thru 40
Balls per Game
Enter 1 thru 5
Threshold Mode
Enter 0 thru 3; 0=0, 1=Points, 2=Extra Ball, 3=Replay
Special Mode
Enter 0 thru 3; 0=0, 1=Points, 2=Extra Ball, 3=Replay
HiScore Mode
Enter 0 thru 3; 0=0, 1=1 Replay, 2=2 Replays, 3=3 Replays
Sound Mode
Enter 0 thru 3; O=Chimes
wlo
background, 2=Sounds
wlo
background
1=Chimes with background, 3=Sounds with background
German Meter
Enter 0 or 1; 0 disables match. 1 enables match
Enter 0 or 1; O=No credits displayed, 1=Displayed credits
Enter 0 or 1; O=Only 1 award per game, 1=More than 1 per game
Enter 0 or
65;
O=Coins, 65=Free Play
Enter 0 or 1 ; O=No slingshots, 1=slingshots
Enter 0 thru 3; O=No warning, 1=1,2=2, 3=3
German Prize
Match Option
Credit Display
No Limit Replays
Free Play
Slingshot
Tilt Warning
10
3
3
3
3
3
o
1
1
1
o
1
1
1-4
