Back Panel Assembly
Part Number
11-1466.1
A-14265-13
03-8171-16
03-10020
31-35410048
31-3541-3C
03-8247-7
03-8319-7
A-23298-5
Part Number Description
4008-01005-52
MS, 8-32 x 3lA- P-PH
4700-00011-00 FW, .172
x
.437
x .059
4408-01119-01
Nut, 8-32 ESN
H-23184
Cable Assembly
03-7655-4
lABCable Clamp
A-17802
W-B Socket wIBracket
24-8802
Bulb #906
4108-01219-08
SMS, #8 x
V2-
Lg. P-H-AB
4104-01001-0&
SMS, #4 x
3/8-
Lg. P-H-AB
Description
Wood Back Panel
Receptacle & Socket (Clear)
Twist-Lock Mini Dome (yellow)
Playfield Plastics Standoff
Playfield Plastic
Playfield Plastic
Double Starred Short Post
No.8 Starred Post
Playfield Plastic Assembly
Item
10
11
12
13
14
15
16
17
18
*Note: Playfield Plastics are not availabfe separately. They must be purchased
as a
complete set
2-26
