2 SWITCH FLIPPER BunON ASSEMBLY
04-12612
SIJ 2
KEYCL!
Top View
ee
Schematic
Side View
Left Side Flipper
J1-1 Black, Ground from Power Driver Board at J113-1 0
J1-2 Key
J1-3 Black-Blue, Flipper Button from Power Driver Board at J113-7
J1-4 Black-Gray, Feature Button from Power Driver Board at J113-9
Right Side flipper
J1-1 Black, Ground from Power Driver Board at J113-1 0
J1-2 Key
J1-3 Black-Green, Flipper Button from Power Driver Board at J113-6
J1-4 Black-Violet, Feature Button from Power Driver Board at J113-8
3-14
