UPPER PLAYFIELD PARTS LOCATONS
U!m
part Number
Description
H!m.
Part Number
Description
1
A-15849-R-2 Upper Right Flipper Assy.
36
A-17313-2
Flipper Return Frame Assembly
1a)
20-9250-5
Flipper Paddle & Shaft
37
A-17234
Bottom Arch Kickback
2
A-16757
Catapult Asserri>ly
38
A-15849-L-2
Left Flipper Assembly
3
A-17313-1
Flipper Return Frame
39
B-9362-L-2
Left Kicker Coil & Bracket
4
A-17081-R Right Gun Assembly
39a)
B-12665
Nylon Kicker
4a)
A-17220-R Gun Motor Bracket wlMotor
40
B-9362-R-2
Right Kicker Coil & Bracket Assy
4b)
A-17084
Bushing
40a)
B-12665
Nylon Kicker
5
12-7098
Right Wire Ramp
41
A-16959
Switch Gate Assembly
6
A-14691-6
Yellow Standup Target
7
12-7161
Right Loading Wire Ramp
8
A-17049-1
Ball Popper Complete
8a)
A-16510
Ball Popper Outer Housing
Parts Under Bottom Arch
9
A-15849-R-2 Upper Right Flipper Assy.
part Number
Description
10
12-7162
Catapuh Wire Ramp
11
A-15658-4
Red Oblong Standup Target
31-1008-50023 Screened Bottom Arch
12
12-7163
Crossover Wire Ramp
12-7122
Wire Fence
13
B-9414-3
Jet Bumper Assembly
20-9041
Tinnerman Speednut
13a)
B-12030-2
Jet Bumper Leaf Switch
20-9601
#8-32 Nut Retainer
13b)
A-9415-2
Jet Bumper Coil Assembly
13c)
03-8254-9
Jet Bumper Cap
14
A-17015
Plastic Ramp
14a)
01-11591
Ramp Flap
Not Shown
15
A-16626
Upper Housing Assembly
16
A-17485
Shuttle Craft Assembly
Pan t:hnnbe[
Description
17
A-17219
Borg Bracket Assembly
17a)
A-17290
Borg Plateform Welded Assy.
A-16765
Ball Trough Assembly Complete
17b)
03-8996
Borg Ship
03-8962-1
"Full Playfield Mylar
18
A-14615
1-Bank Drop Target
16-50023-1
Instruction Card
19
A-16759
Black Standup Target
20-6500
Steel Ball
20
A-16763
Divertor Assembly
20a)
01-12215
Divertor
20b)
A-17630
Shaft
21
A-17484
Romulan Ship
'The
STAR TREK
hardcoat
playfield does
22
A·17330
2·lamp PCB
23
A-14690-6
Yellow Standup Target
not require a full mylar.
However Mylars
24
03-8994
Klingon Ship
can be purchased through your local
24a)
12-7150
Klingon Ship Support Wire
WIlliams Distributor.
25
A-16959
Switch Gate Assembly
26
A·16811
Plastic Ramp
26a)
01-11635
Flap
26b)
A-17272
2·lamp PCB
27
A-16756
Plastic Ramp
27a)
01-11819
Flap
28
A-17022
Spin Target
29
A-17049
Ball Popper Complete
29a)
A-16387
Ball Popper Outer Housing
30
A-17049-1
Ball Popper Complete
30a)
A-16421
Ball Popper Outer Housing
31
A-14691-4
Red Stand up Targets
32
A-14691-6
Yellow Standup Targets
33
12-7097
Left Wire Ramp
34
12-7160
Left Loading Wire Ramp
35
A-17081-L
Left Gun Assembly
35a)
A·17220-L
Gun Motor Bracket
wI
Motor
35b)
A·17084
Bushing
's'iilil 'iilEn
71IEREXT GEREUnDR 2-36
