STAR TREK
Unique Parts List
Pan
Number
Description
Pan Number
Description
A-12742-50023
WPC CPU Assembly
A-17416
Standup Switch
&
Bracket Assy.
A-13204-50023
Bottom Arch Assembly
A-17418
Kicker Switch Assembly
A-13769-50023
Playfield
&
Insert Assembly
A-1744S-1
6-Ball Cashbox Assembly - Multiple
A-16123-50023
Backbox Assembly
A-17483
Klingon Ship Assembly
A-16387
Ball Popper Hsg. Welded Assy.
A-17484
Romulan Ship Assembly
A-16421
Ball Popper Outer Hsg. Welded Assy.
A-17489-1
50023-Playfield Plastic Assy.
A-16622
Ball Guide Assembly
A-17489-2
50023-Playfield Plastic Assy.
A-16623
Ball Guide Assembly
A-17489-3
50023-Playfield Plastic Assy.
A-16624
Ball Guide Assembly
A-17489-4
S0023-Playfield Plastic Assy.
A-16626
Upper Housing Assembly
A-17489-S
S0023-Playfield Plastic
Assy.
A-16756
U-Plastic Ramp Assembly
A-17489-6
50023-Playfield Plastic Assy.
A-16757
Catapult Assembly
A-17S09
U-Ball Guide
&
Opto Assembly
A-16759
Standup Target Assembly
A-17510
U-Load Rp./Popper Hsg. Assy. - R.
A-16763
Divertor Assembly
A-17S11
U-Load Rp./Popper Hsg. Assy. - L.
A-16773
Lever Guide Assembly
A-17S12
U-Ball Guide
&
Opto Assembly
A-16811
U-Plastic Ramp Assembly
A-17615
Divertor Actuator Shaft Assy.
A-16852
Ball Guide Assembly
A-17628
Bracket - Support
A-16853
Ball Guide Assembly
A-17630
Divertor Shaft Staked Assy.
A-16854
Ball Guide Assembly
A-17631
Divertor Shaft Staked Assy.
A-1686S
Ball Guide Assembly
A-17632
P~d. Lamp Sub Cable Assy.
A-16917-50023
Sound Board Assembly
A-17652
Ball Guide
A-16920-1
6-Lamp Board & Spacer Assy.
A-17657
Wood Back Panel Assembly
A-16922-1
Prox Sensor II Assy. w/Spacer
A-85S2-50023
Backglass Assembly
A-16959
Switch Gate Assembly
A-17012-1
6-Lamp Board & Spacer Assy.
C-10843-2
Metal Leg Assembly
A-17013-1
5-Lamp Board & Spacer Assy.
A-17014-1
3-Lamp Board
&
Spacer Assy.
01-11410
Ball Guide
A-17015
U-Plastic Ramp Assembly
01-11412
Ball Guide
A-17022
Spin Target Assembly
01-11658
Ball Guide
A-17023
Wireform
&
Target Assembly
01-11679
Bracket - Support
A-17049
Ball Popper Assembly
01-11700
Ball Guide - Bottom Arch Right
A-17049-1
Ball Popper Assembly
01-11701
Ball Guide - Bottom Arch Left
A-170S4
SpeakerlDisplay Panel Assy.
01-12215
Divertor
A-16054
Ind.
&
Eddy Sensor Cable Assy.
01-12227
Ball Deflector
A-17078
U-Trough Assembly
A-17081-L
Gun Assembly - Left
02-4930
Divertor Shaft Rear
A-17081-R
Gun Assembly - Right
02-4931
Divertor Shaft (Pivot)
A-17082-L
Driver Plate Assembly - Left
A-17082-R
Driver Plate Assembly - Right
03-8985
Sensor retention Clip
A-17084
Bushing Assembly
03-9026
Gun Cover
A-1719S
Tilt Switch Assy. w/Cable
A-17219
Borg Bracket Assembly
12-7097
Wire Ramp, Left
A-17220-L
U-Gun Motor Brkt. - Left
12-7098
Wire Ramp, Right
A-17220-R
U-Gun Motor Brkt. - Right
12-7119
Wire Ramp Catapult
A-17221-1
Coin Door Interface & Spacer Assy.
12-7162
Wire Ramp
A-17223
16-Opto Board & Brkt. Assembly
12-7163
Wire Ramp
A-17234
Bottom Arch Kicker Assembly
A-17313-1
Flipper Return Frame Assy., Right
20-9663-16
Start Push Button
w/Sw,
Yellow
A-17313-2
Flipper Return Frame Assy., Left
20-9663-17
Push Button
w/Sw,
Green
A-17330
2-Lamp Board & Brkt. Assembly
A-17343
G.!. Cable & Socket Assembly
31-1808
Matrix Label Insert
A-17356-1
26-Lamp Board & Spacer Assy.
36-50023
Playfield Hard Coat
's,i1i1
m&i\
1NEIIEXT 6EIIEUnllll
2-34
