Adjustment A.2 17 Is set to ON.
This is a reminder to the operator that the adjustment, "Left Launcher Broken", is set to ON. This
adjustment must be set to OFF once the launcher is fixed.
Adjustment A.2 18 Is set to ON.
This is a reminder to the operator that the adjustment, "Right Launcher Broken'" is set to ON. This
adjustment must be set to OFF once the launcher is fixed.
Gun Cannot Find Home -Left
The Left Gun Home switch needs attention. Either the switch is out of alignment, or there is an
open connection between the switch and the 8-driver board, or Q12 on the 8-Driver Board failed,
or U19 on the CPU Board failed.
Gun Cannot Find Home -Right
The Right Gun Home switch needs attention. Either the switch is out of alignment, or there is an
open connection between the switch and the 8-driver board, or Q12 on the a-Driver Board failed,
or U19 on the CPU Board failed.
