4. Reach into the cabinet and backbox and ensure that the interconnecting cables are not kinked or
pinched.
Be careful to avoid damaging wires at any stage of the assembly process.
5. Raise the hinged backbox upright and latch it into position.
Unlock the backbox, and remove the
backglass.
Remove the shipping screws holding the Insert Panel. Unlatch and open the Insert Panel.
Carefully lift up the Speaker Panel and lay it down on the playfield glass. (Be careful not to damage the Dot
Matrix Display/Driver.)
This allows access to the bolt holes used for securing the back box upright. To
secure the backbox, install the washer-head mounting bolts through the bottom holes of the backbox into
the threaded fasteners in the cabinet.
Close and latch the Insert Panel. Replace the Speaker Panel.
Reinstall the backglass, and lock the backbox.
&
CAUTION
FAILURE
TO
INSTALL
the backbox mounting hardware properly can cause personal injury.
NEVER
TRANSPORT
a pinball game with the hinged backbox erect. Always lower the back box forward onto
the playfield cabinet on a layer of protective material to prevent marring or damage and possible personal
iniJry·
6. Extend each leg leveler
slightly
below the leg bottom, so that all four foot pads are extended about the
same distance. Remove the cabinet from ns support
am
place it on the floor.
7. Unlock and open the coin door. Move the rrolding latch lever toward the left side of the game. Lift the
front molding off the playfield cover glass return the latch lever toward the right, and close the coin door.
Carefully slide the glass downward, until it clears the grooves of the left ard right side moldings. Lift the
glass up and away from the game. Raise the playfield. (See page 1-5.)
8. The gun handle is mounted inside the cabinet behind the partition.
Remove the gun handle from its
location and position it on the outside top right comer of the cabinet, (see diagram). Fasten the handle in
place with the hardware shiRJed in the unique parts bag.
ESN Nut
<,
<,
"-
<, '~
~
9. Lower the playfield.
Place a level or an inclinometer on the playfield surface. Adjust the leg levelers for
proper playfield level (side-to-side).
NOTE:
It is recommended that this measurement be made ON the
playfield, not the cabinet nor the playfield cover glass. TIghten the nut on each leg leveler shaft to
maintain this setting.
